Home > Electrical & Electronics > Switch > Other Switches > Load Isolation Switch Change Over Switch

Load Isolation Switch Change Over Switch

Name: Load Isolation Switch Change Over Switch
Brand: ZGQT
SKU: 124024643
Availability: InStock

Load Isolation Switch Change Over Switch thumbnail-1

Load Isolation Switch Change Over Switch thumbnail-2

Load Isolation Switch Change Over Switch thumbnail-3

Load Isolation Switch Change Over Switch thumbnail-4

Load Isolation Switch Change Over Switch photo-1

Load Isolation Switch Change Over Switch photo-2

Load Isolation Switch Change Over Switch photo-3

Load Isolation Switch Change Over Switch photo-4

US$ 10 - 2,500 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

ZGQT

Model Number:

QGLZ1 HGLZ1

Contact Supplier Request Quote Chat Now

Zhejiang Qiantai Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name ZGQT

Model Number QGLZ1 HGLZ1

Max. Current 6A 3200A

Max. Voltage 220V 380V 690V

QGL(HGL) series load isloation switch (hereinafter called switch for short) is manfactured by our company with the up-to-date technique imported from Europe .This product meets the international technial level in the late 1990S.Being the most ideal renewal of domestic congeneric products.

This kind of lode isolation switch is widely used in the distribution system and automatic system of architecture,electrical power,petrochemical,and other industries.

This kind of lode isolation switch possesses flexible structure of modularized design,possesses fiexible and versatile compositionality ,it adopts the shell made by unsaturated polyester resin reinforced by glassfibre.It has very high dielectric performance .protective capability,and reliable operation.

The operating mechanism is an elatic-accumlulating accelerating mechanism for instant on and off of the double breakpoint contact ,It has no relationship with the speed of operating handle and increases greatly various electric properties.

Many forms of structres and operations in which the on and off state of contact is observed through windows.There are operations inside and outside the board .There are frontal and lateral poerations.There are connections behind the board .

This kind of swich has a good-looking outline and various functions ,being very novel,simple and small-dimensioned ,and the best choice among the congeneric prouducts.

The QGL(HGL) series prouduct has acquired the 3C attestation certificate.

1.QGL-63A/3

QGL-63A/4

SUIT FOR RATED CURRENT IN(A):40A 63A

QGL(HGL) electrical properties and pechanical properties

Conventional thermal current lthA			63A
Rated impulse withstand voltage(A)			40	63
RAted surge-resistant voltage Uimp KV			6	6
Rated working current le	380V	AC-21	40	63
		AC-22	40	63
		AC-23	40	50
	660V	AC-21	40	50
		AC-22	32	32
		AC-23	25	25
	220V	DC-21	32	63
		DC-22	40	63
		DC-23	40	63
	440V	DC-21
		DC-22
		DC-23
Rated breaking capability lcn			320	504
Rated short-current making capability lcm (KA peak value)			7.5	7.5
Mechanical durability			10000	10000
Electric durqbility Ue=660V,Rated current le		cosa=0.95 AC21	1700	1700
		cosa=0.65 AC22	100	100
		cosa=0.35 AC23	500	500
Weight(kg)		3poles	0.37	0.37
		4poles	0.41	0.41

QGL-100A/3

QGL-100A/4

SUIT FOR RATED CURRENT IN(A):80A 100A

QGL(HGL) electrical properties and pechanical properties
Conventional thermal current lthA			100A
Rated impulse withstand voltage(A)			80	100
RAted surge-resistant voltage Uimp KV			6	6
Rated working current le	380V	AC-21	80	80
		AC-22	80	80
		AC-23	80	80
	660V	AC-21	80	80
		AC-22	50	50
		AC-23	40	40
	220V	DC-21	80	100
		DC-22	80	80
		DC-23	63	63
	440V	DC-21
		DC-22
		DC-23
Rated breaking capability lcn			640	800
Rated short-current making capability lcm (KA peak value)			10	10
Mechanical durability			10000	10000
Electric durqbility Ue=660V,Rated current le		cosa=0.95 AC21	1700	1700
		cosa=0.65 AC22	100	100
		cosa=0.35 AC23	500	500
Weight(kg)		3poles	0.37	0.37
		4poles	0.41	0.41
