Factory Price 100% New Material China Top Manufacture PPR Plastic Pipe
US$ 1 - 80
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
YUNKAI
Model Number:
YK-PR206
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DIN 8077-8078 Standard Ppr Pipe PriceUS$ 1 - 80MOQ: 1000 Meters -
DIN 8077-8078 Ppr Pipes Water Supply Ppr Pipe Din 8077-8078 Standard Ppr Pipe PriceUS$ 1 - 80MOQ: 1000 Meters
-
2 Inch Round Plumbing Materials Ppr Pipe for Cold Hot Water SupplyUS$ 0.5 - 18MOQ: 1000 Meters
-
Factory Price PN2.0 Hot Water Ppr Pipe and FittingUS$ 0.5 - 18MOQ: 1000 Meters
-
Price of PN 1.25 PN 1.6 Cold Water Transfer Pipes PprUS$ 0.5 - 18MOQ: 1000 Meters
Place of Origin
China
Brand Name
YUNKAI
Model Number
YK-PR206
Material
PP
Specification
20mm-1400mm
Length
4-5.8m each piece
Thickness
20mm-160mm
Standard
DIN, Germany Din8077/8078,ISO9001
- Material: Random Polypropylene and alloy aluminium compound
- Sizes: 20 to 160mm
- Pressure Rating: 1.25MPa, 1.6MPa, 2.0MPa ,2.5MPa
- Colors: grey, white or other colors on request
- Connection: socket fusion joint, electro fusion joint or transition joint
- Certification: CE ISO9001, ISO14001,
- Applications: Cold or hot water supply, heating system including flooring heating, wall heating and radiating system, Central air conditioning system, industrial liquids transportation
Advantages
High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius
- Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe
- Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
- Corrosion Resistant: resist chemical matters or electron chemical corrosion
- Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
- Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes
- Long Life: more than 50 years under normal conditions
- Recycled and Environment-friendly
Detailed Images
|
SIZE |
PN 1.0MPa |
PN 1.25MPa |
PN 1.6MPa |
PN 2.0MPa |
|
Outer Diameter (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
20 |
2 |
2.3 |
2.8 |
3.4 |
25 |
2.3 |
2.8 |
3.5 |
4.2 |
32 |
2.9 |
3.6 |
4.4 |
5.4 |
40 |
3.7 |
4.5 |
5.5 |
6.7 |
50 |
4.6 |
5.6 |
6.9 |
8.3 |
1. For Hot and Cold water installations in Residences, Complexes, Apartments, Offices, 2.Hospitals, Hotels, Schools etc.
3. Rain Water Harvesting
4. For Agriculture and Horticulture use
5. Compressed Air Plants
6. Swimming Pools
7. Transportation of Corrosive Fluids such as acids etc.
