Overview
OEO6500-GWDM is a service board for WDM-GPON system launched by Sino-Telecom. It regenerates optical signals in the principle of optical-electrical-optical to realize the amplification of optical signals. Moreover, clock extraction is realized by using downlink signal to realize retiming of signals, and further to achieve 3R amplification of signals. It can effectively amplify the optical power of PON line and prolong network transmission distance. With features of compact structure and easy installation, it can be widely used in fields of various bandwidth expansion, remote transmission, GPON access of residential community and FTTH etc.
Features
- It supports optical power amplification of GPON optical lines, as well as transparent transmission.
- 3R regeneration and amplification of optical signals is realized by clock extraction.
- PON transmission distance is effectively prolonged to over 60KM.
- It supports the networking mode of cascade connection of several devices.
- Optical channel for 1550nm wavelength is reserved, which can share an optical fiber with digital CATV signals.
- It supports a variety of management modes such as SNMP, serial port and ethernet port etc.
- The board is hot-pluggable.
Performance Specifications
|
Transmission Performance | |
| Protocols | GEPON(IEEE 802.3 ah) |
| Downlink Rate | 2.488G and 1.25G continuous signal |
| Uplink Rate | 1.25G burst signal |
| Compatibility | Compatible with OLT and ONU devices from different manufactures; It supports transparent transmission of optical signals and optical channel for 1550nm wavelength is reserved |
| Transmission Distance | It supports a maximum transmission distance of over 60km |
| Optical Interface Parameters | |
| Receiving Sensitivity at OLT Side |
-28/-3 dBm(2.5G/bps) -30/-3 dBm(burst) |
| Receiving Sensitivity at ONU Side | -28/-8 dBm(burst) |
| Transmitting Optical Power at OLT Side | 1 dBm |
| Transmitting Optical Power at ONU Side | 2 dBm |
| Operating Environment | |
| Temperature | -10 to 70℃ |
| Humidity | 5 to 85% |
| Power Consumption | <15W |
Application
Product Category
1. WDM Optical Transport System 2. Optical Line Protection Switch
3. xDSL 4. GPON/EPON
5. Lawful Interception 6. Network Interface Card
7. TAP 8. Wireless AP
