Specifications
Onvif Camera wireless full hd p2p ip camera 2.0 megapixel1. CMOS, H.264
2. Onvif Compliant
3. iPhone/iPad/Android Mobile
Onvif Camera wireless full hd p2p ip camera 2.0 megapixel
Mega pixel Wireless IR Bullet Camera-GRT-MIPD510A-W1 Series
Function Feature:
H.264 Main Profile @level 3
Support P2P protocal and support plug and play(Support iPhone/Android Mobile)
2.0 Megapixel 1600*1200 Resolution
Dual H.264 Stream, resolution, frame rate, bit rate adjustable
Support RTSP Compatible with VLC Media Player
Onvif Compliant, Support Milestone/Axxon/NUUO/Geovision
Support Two Way Audio
Support Motion Detection
1/4" CMOS Sensor Progressive Scan
2.8/3.6/6 mm Mega Pixel Fixed Lens included
Ø5 11pcs IR LED IR Range 10 m
Support Power over Ethernet (IEEE 802.3af) optional
Support TF Card (Max. 32GB) Optional
IP65 Rated, Indoor Use
Support iPhone/iPad/Android Mobile
Support Intelligent Video Analytics Software
Optional model
GRT-MIPD510A-W
Specification:
Model |
GRT-MIPD510A-W1 Series |
||
Hardware | |||
Sensor |
1/4" Progressive Scan CMOS OV2643 |
||
Effective Pixels |
1600(H)×1200(V) |
||
Min.Illumination |
1250mv/lux-sec |
||
Day/Night |
Auto,dual IR-Cut filter |
||
IR LED |
Ø5 11pcs IR Leds IR Range 10 m |
||
Max S/N Ratio |
39dB |
||
Electronic Shutter |
Rolling Shutter |
||
Rotation |
Pan: 355°, Tilt: 90°, Tour: 15°/s |
||
Interfaces | |||
Optical lens |
Interface |
MTV mount (interchaeable lens) |
|
Lens |
Fixed Iris, Manual Focus |
||
Focal Length |
Fixed-Focal, f2.8/3.6/6 mm / F1.6 |
||
H View Angle |
62.2° |
||
Audio Talkback |
1 channel power MIC input, External access, AV interface |
||
Audio Output |
1 channel power speaker output, AV interface |
||
Storage Interface |
Micro SD (TF) Card supports video storage and image snapping; |
||
Network Interface |
Lan |
10/100M BASE-TX,RJ-45 connector |
|
RS485 |
Default as RS485 port for PTZ, 1ch Alarm input or 1ch alarm output optional |
||
Audio video encoding | |||
Video Compression |
H.264 Main Profile; MJPEG/JPEG Baseline |
||
Resolution |
Main Stream |
UXGA (1600*1200) 1-15fps, HD 720P (280*720) 1-25fps |
|
Sub Stream |
CIF(352*288)/QVGA(320*240)/QCIF(176*144) 1-30fps |
||
Video Bitrate |
32Kbps~4Mbps,Supports CBR/VBR |
||
Title OSD |
Supports channel name, date, and video stream information overlay; |
||
Privacy Mask |
4 configurable regions |
||
Image Orientation |
image flip and mirror |
||
Auto Image Control Functions |
Auto Exposure Control (AEC); Auto White Blance (AWB); Auto Band Filter (ABF)Auto Black Level Calibration (ABLC) |
||
Image Controls |
Color saturation, hue, gamma, sharpness (edge enhancement), lens correction, |
||
Audio Compression |
G.711 |
||
Two Way Audio |
Support |
||
Data transmission and storage | |||
Data storage |
Video and Image |
||
Recording |
Recording set up to record by motion trigger,alarm trigger, manual, or schedule |
||
Alarm Output |
FTP,E-mail, Explorer, Software |
||
Network protocol |
TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,NTP,SMTP,UPNP |
||
Wireless protocols(-W) |
802.11b/g/n, 150Mbps, Supports WEP,WPA,WPA2("-WiFi" model supports) |
||
ONVIF protocols |
Support 1.02 version |
||
Remote View |
PC |
IE 6.0 or later, max 10 users |
|
Mobile Phone |
iPhone, Android, Blackberry Mobile |
||
General Parameters | |||
Environmental Casing |
Indoor Use |
||
Installation |
Brackets Included, Wall Mount |
||
Operating Temperature |
-20 °C ~ 50 °C (-4 °F ~ 122 °F) for DC 12V |
||
Operating Humidity |
0% -85% RH |
||
Power |
DC12V 2.0A |
||
POE |
POE Class 3 IEEE802.3af, optional for "-POE" Model |
||
Power Consumption |
9W(MAX) |
||
Dimension |
180(L) * 160(W) * 100(H)mm |
||
Weight |
0.36KG (2.2lb) |
||
Package Dimension |
328(L) * 150(W) *148(H) mm |
||
Package Weight |
1.62KG (3.57lb) |
||
Approvals |
CE FCC RoHS |
||
