Help CenterClearly Checked Universal Fiber Optic Inspection Microscope
Related Products
-
Handheld Microscope Fiber Optic Connector InspectionUS$ 818.9 - 881.9MOQ: 1 Set -
FK-7500A Handheld Optic Inspection Fiber MicroscopeUS$ 708.7 - 771.7MOQ: 1 Set
-
FC SC ST E2000 LC MU MPO Compatible Handheld Fiber Optic MicrscopeUS$ 678 - 707MOQ: 1 Piece
-
Built in IR Filter FK-H400 Handheld Fiber Optic Inspection MicroscopeUS$ 63 - 94.5MOQ: 1 Piece
-
400X Benchtop Optic Fiber Inspection MicroscopeUS$ 308 - 330MOQ: 1 Set
Clearly checked universal fiber optic inspection microscopClearly checked universal fiber optic inspection microscope
1.Scratches can be clearly checked and resolution 0.5μm
2.Smooth focus control, simple operation, stable testing results
3.HD 8 Inch LED Display for sharp and clear image shown
4.Build-in blue light provides extra sharp image
5.200× and 400 × magnification optionable
| 1.Magnification/Resolution | 400X/0.5μm or 200 X/0.75μm |
| 2.Light Source/Service Life | Coaxial Blue LED,50000 hrs |
| 3.LED Display size | 20.4*16.2cm (8 Inch) |
| 4.Image Size | 200X: 40mm;400X: 80mm |
| 5.Optical Zoom | 400x |
| 6.Adapter | Universal 2.5mm and 1.25mm Adapter |
| 7.Total L*W*H | 230*92*145mm |
| 8.Total Weight | 1.6Kg |
| 9.Materials | Iron 80%+ plastic 20% |
Features
1.Fiber end face inspection with diameter 1.25mm and 2.5mm for patchcord
2.Patchcord inserted directly to the microscope, improves testing efficiency
3.High-manification to observe all kinds of connector endface
4.High definition and resolution
5.High accuracy to locate ferrule center
6.LED display scratches/chips/dents/dust easily and clearly
Applications
1.Bench-top microscope with diameter 1.25mm and 2.5mm for patchcord
2.Universal adapters inspecting for ST, SC, FC, MU and LC ferrules
3.Finished, half-finished, PC and APC all types can be tested
4.Suitable for patch cord manufacturers and laboratories application
What does NEOFIBO offer?
We offer full range of quality and comprehensive fiber optic products, including Patchcord Production Machine, polishing jigs, as Seikoh Giken, Senko, Domaille or customized ones; Polishing Consumables, Tools, Cleanings, Tool Kits, Testing Equipment, Splice Items. We commit to offer you Attractive Price, Excellent Quality and Fast Delivery!
What will be the delivery cost?
All price listed are FOB Shenzhen. Your nominated courier is acceptable. Otherwise, we will use FEDEX, DHL, UPS or any other forwarder per confirmation and charge accordingly.
How the goods will be delivered?
For normal stock items, they will be dispatched within 1-2 business days after payment confirmation. However, for items out of stock, estimated leadtime will be 3-10 working days.
How can I order the goods?
NEOIFBO are pleased to offer our valuable customers three ordering channels, ie., Online Ordering, Fax Order Form and Issuing Formal Purchasing Order by mail.
How is the warranty for NEOFIBO product?
All products are warranted by NEOFIBO (consumables, normal tear and wear excluded) for one year after date of purchase. Any part defected in material or workmanship and returned to NEOFIBO, as NEOFIBO designates, shipping costs prepaid, will be, as the exclusive remedy, repaired or replaced, at NEOFIBO's option.
