Help CenterAPI Grade G105 S135 X95 Internal Coating Drill Pipe
Related Products
Usage: As the major part of drill stem, drill pipe connected with Kelly and drill collar, which is used to put torque to drill bit and drill collar.
Material: G105, S135, X95, Grade E etc.
Standard: According to API Spec 5D standards. ALSO WE CAN SUPPLY DS-1 and NS-1 STANDARD.
Hard band: Arnco100XT, Arnco200XT and Arnco300XT; Botn1000, Botn3000, TCS8000, TCS-Titanium, Armacor M etc. Also we can make according to customers’ requirements.
Internal coating: DPC, TK34, TK34P, TK34XT, TC2000, TC3000
Size: OD 2 3/8”----6 5/8”
Length: R1: 5.49-6.71m, R2: 8.23-9.14m, R3: 11.58-13.72m
Upset style: IU, EU, IEU
Detail Specification:
Technical specification and parameters for Drill Pipe | |||||||||
Size |
Weight Designation |
Calculated Plain-End Weight |
Outside Diameter |
Grade |
Wall Thickness |
Upset Ends. For Weld-on Tools Joint |
|||
Lb/ft |
kg/m |
in |
mm |
In |
mm |
||||
2 3/8 |
6.65 |
6.26 |
9.32 |
2.375 |
60.3 |
E,X,G,S |
0.280 |
7.11 |
EU |
2 7/8 |
10.40 |
9.72 |
14.48 |
2.875 |
73.0 |
E,X,G,S |
0.362 |
9.19 |
IU or EU |
3 1/2 |
9.50 |
8.81 |
13.12 |
3.500 |
88.9 |
E |
0.254 |
6.45 |
IU or EU |
3 1/2 |
13.30 |
12.31 |
18.34 |
3.500 |
88.9 |
E,X,G,S |
0.368 |
9.35 |
IU or EU |
3 1/2 |
15.50 |
14.63 |
21.79 |
3.500 |
88.9 |
E |
0.449 |
11.40 |
IU or EU |
3 1/2 |
15.50 |
14.63 |
21.79 |
3.500 |
88.9 |
X,G,S |
0.449 |
11.40 |
EU or IEU |
4 |
14.00 |
12.93 |
19.26 |
4.000 |
101.6 |
E,X,G,S |
0.330 |
8.38 |
IU or EU |
4 1/2 |
13.75 |
12.24 |
18.23 |
4.500 |
114.3 |
E |
0.271 |
6.88 |
IU or EU |
4 1/2 |
16.60 |
14.98 |
22.31 |
4.500 |
114.3 |
E,X,G,S |
0.337 |
8.56 |
EU or IEU |
4 1/2 |
20.00 |
18.69 |
27.84 |
4.500 |
114.3 |
E,X,G,S |
0.430 |
10.92 |
EU or IEU |
5 |
16.25 |
14.87 |
22.15 |
5.000 |
127.0 |
X,G,S |
0.296 |
7.52 |
IU |
5 |
19.50 |
17.93 |
26.71 |
5.000 |
127.0 |
E |
0.362 |
9.19 |
IEU |
5 |
19.50 |
17.93 |
26.71 |
5.000 |
127.0 |
X,G,S |
0.362 |
9.19 |
EU or IEU |
5 |
25.60 |
24.03 |
35.79 |
5.000 |
127.0 |
E |
0.500 |
12.70 |
IEU |
5 |
25.60 |
24.03 |
35.79 |
5.000 |
127.0 |
X,G,S |
0.500 |
12.70 |
EU or IEU |
5 1/2 |
21.90 |
19.81 |
29.51 |
5.500 |
139.7 |
E,X,G,S |
0.361 |
9.17 |
IEU |
5 1/2 |
24.70 |
22.54 |
33.57 |
5.500 |
139.7 |
E,X,G,S |
0.415 |
10.54 |
IEU |
6 5/8 |
25.20 |
22.19 |
33.05 |
6.625 |
168.3 |
E,X,G,S |
0.330 |
8.38 |
IEU |
6 5/8 |
27.70 |
24.21 |
36.06 |
6.625 |
168.3 |
E,X,G,S |
0.362 |
9.19 |
IEU |
Standard exporting package by Senwell or according to customers' request
Shipping: China main port (Tianjin & Shanghai for selection)
1.High quality products with favorable price at a right delivery.
2.Customized design
3.Warranty
SENWELL's main products cover 220 types and more than 1000 specifications presently. Our business covers non-magnetic products, drilling stem tools, fishing tools, jarring tools, coring tools, cementing tools, milling tools, well head tools, accessory tools, downhole tools, oil mining equipment, drill equipment, well control systems and pipes.
Today, with strong technology and profuse experience, SENWELL not only provides a comprehensive range of oilfield tools, but also provides tools for machinery industry and has decades of production experience. Main products are sand casting, investment casting, forging, centrifugal casting and machining equipment.
We have a great deal of outstanding and seasoned employees. Relying on advanced equipment and techniques, with the scientific management theory and spirit of "seriously dealing with matters relating to works", we have established long-term cooperative relationships with more than a hundred famous and large manufacturers in China. Our company creates a steady-going and reliable environment for our product research, development and sale.
We are based on the tenet of "providing consistent high quality products and the best services to meet the strict needs of our customers; to create value for our customers and provide our customers with a return on their investment" and the business philosophy of "people-oriented, customer first and reliability first". Our products have been successfully exported to Europe, America, the Middle East, South Africa and Southeast Asia. In the international market, we have acquired an excellent reputation among the clients.
We welcome new and old customers from all over the world to contact us for future business relationships and achieving mutual success! To benefit from our strong OEM/ODM capabilities and considerate services, contact us today. We believe you will be better with our support!
When enquiry, please kindly specify below:
1) size of OD, ID(if necessary)
2) Material
3) Length
4) Connection
5) Delivery (Port of destination if need a CIF price; ideal date of delivery)
