Help CenterChina High Quality Alloy Steel Plain End Oil Tubing for Oilfield
Related Products
-
Oil and Gas Steel TubeNegotiableMOQ: 1 Piece -
Api 5ct Oil Casing Pipe for Oilfield Well DrillingNegotiableMOQ: 1 Piece
-
4 1/2"~20" Seamless Steel Casing / Api 5CT Casing/ J55 Casing in R2NegotiableMOQ: 1 Piece
-
API Spec 5CT Standard Oil Casing / Hot Sales Cold-rolled Oil Casing / High Quality Oil Casing for SaleNegotiableMOQ: 1 Piece
-
8 5/8 Api CasingNegotiableMOQ: 1 Piece
Specifications
Standard: API 5CT,Steel grade: J55, K55, N80, C90, P110, Q125
Size: 1.05--4 1/2"
Length: R1 / R2/ R3
Tubing
Standard:API SPEC 5CT Standard.
Use: Seamless steel tubes for oil casing and tubing in oil and gas well. Tubing is mounted in the production casing after the oil well is dig and cemented, it is seamless pipe to transport oil gas to ground surface.
Steel grade: J55, K55, N80, L80, C90, T95, P110, Q125
Size: 4 1/2”~20” for Seamless Casing
1.05”~4 1/2” for Seamless Tubing
Length: R1/R2/R3
Dimensional tolerances:
|
Types of steel tubes |
Outer diameter |
Wall thickness |
|
Cold-rolled tubes |
Tube sizes(mm) |
Tolerances(mm) |
Tolerances(mm) |
<114.3 |
±0.79 |
-12.5% |
|
≥114.3 |
-0.5%, +1% |
||
Mechanical properties:
Standard |
Models of steel tubes |
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Hardness |
API SPEC 5CT |
J55 |
≥517 |
379~552 |
check the table |
≤241HB |
K55 |
≥517 |
≥655 |
|||
N80 |
≥689 |
552~758 |
|||
L80(13Cr) |
≥655 |
552~655 |
|||
P110 |
≥862 |
758~965 |
Chemical Composition:
Standard |
Models of steel tubes |
Chemical compositions (%) |
||||||||||
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Cu |
Mo |
V |
Als |
||
API SPEC 5CT |
J55K55 (37Mn5) |
0.34~ 0.39 |
0.2~ 0.35 |
1.25~ 1.5 |
≤0.02 |
≤0.015 |
≤0.15 |
≤0.20 |
≤0.20 |
|
|
≤0.02 |
N80 (36 Mn2V) |
0.34~ 0.38 |
0.2~ 0.35 |
1.45~ 1.7 |
≤0.02 |
≤0.015 |
≤0.15 |
|
|
|
0.11~ 0.16 |
≤0.02 |
|
L80 (13Cr) |
0.15~ 0.22 |
≤1.0 |
0.25~ 1.0 |
≤0.02 |
≤0.010 |
12.0~ 14.0 |
≤0.20 |
≤0.20 |
|
|
≤0.02 |
|
P110 (30CrMo) |
0.26~ 0.35 |
0.17~ 0.37 |
0.40~ 0.7 |
≤0.02 |
≤0.010 |
0.8~1.1 |
≤0.20 |
≤0.20 |
0.15~ 0.25 |
≤0.08 |
≤0.02 |
|
Note: Also we can supply you pup joint and coupling (coupling stock and coupling blank) for tubing and Casing, as well as for weld pipe.
