Help CenterTop Drive System
Related Products
Specifications
TDS is one of the greatest technological revolutions of petroleum equipment which is used to replace Kelly and rotary table.Standard: API SPEC 8C standard
Technical specifications and parameters for Top Drive | |||
Specification |
250Ton |
350Ton |
500Ton |
Nominal drilling depth (5 1/2" drill pipe) |
4,000m(13,000ft) |
5,000m(16,000ft) |
7,000m(23,000ft) |
Rated load capacities |
2,250KN(250t)) |
3,150KN(350t) |
4,500KN(500t) |
Drilling torque (continuous, max.) |
32KN.m |
36KN.m |
54KN.m |
Rotary speed |
0 - 180rpm |
0 - 180rpm |
0 - 220rpm |
Rated power of AC induction motor |
315 KW x 1 |
350KW x 1 |
350KW x 2 |
Tilt angle of tilt arm ( max) |
Forth 30" Back 55" |
Forth 30" Back 55" |
Forth 30" Back 55" |
Maximum torque of break out |
50KN.m |
65KN.m |
80KN.m |
Working pressure of hydraulic system |
16MPa |
16MPa |
16MPa |
Input voltage of driving cabinet |
600VAC |
600VAC |
600VAC |
Range of variable frequency |
Rated 0 - 121Hz |
Rated 0 - 121Hz |
Rated 0 - 121Hz |
More details,you are welcome to contact us by mail!
