Oil Casing Cement Head With Single Plug

Name: Oil Casing Cement Head With Single Plug
Brand: SENWELL
SKU: 123846799
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

SENWELL

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name SENWELL

Specifications

The casing cement-head with single plug is special tools for pumping slurry and releasing plug.

Casing Cement Head with Single Plug

The casing cement-head with single plug is special tools for pumping slurry and releasing plug.

Feature:

Quick-latch adapter is used to provide easier, faster and safer thread connection with API STC/LTC cementing casing.
Indicator shows plug releasing.
Balance pipe is developed.

Detail Specification:

Technical specifications and parameters for Casing Cement Head with Single Plug
Type	DDS				ZDS
size(mm)	139.7	177.8	244.5	339.7	73	88.9	127
Overall length(mm)	1400	1450	1700	1700	910	1012	1125
Manifold interface	2" union
I.D. of plug container(mm)	125	160	225	320	52	72	100
Length of plug container(mm)	450	450	550	550	290	340	405
Max. working pressure	70Mpa	35Mpa	35Mpa	20Mpa	70Mpa	70Mpa	35Mpa
