API Casing Cement Head With Single Plug
Negotiable
/ Piece
1 Piece(Min. Order)
- China Main Port
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | China | Brand Name | SENEELL |
Product Description
Specifications
The casing cement-head with single plug is special tools for pumping slurry and releasing plug.Casing Cement Head with Single Plug
The casing cement-head with single plug is special tools for pumping slurry and releasing plug.
Feature:
- Quick-latch adapter is used to provide easier, faster and safer thread connection with API STC/LTC cementing casing.
- Indicator shows plug releasing.
- Balance pipe is developed.
Detail Specification:
Technical specifications and parameters for Casing Cement Head with Single Plug | |||||||
Type | DDS | ZDS | |||||
size(mm) | 139.7 | 177.8 | 244.5 | 339.7 | 73 | 88.9 | 127 |
Overall length(mm) | 1400 | 1450 | 1700 | 1700 | 910 | 1012 | 1125 |
Manifold interface | 2" union | ||||||
I.D. of plug container(mm) | 125 | 160 | 225 | 320 | 52 | 72 | 100 |
Length of plug container(mm) | 450 | 450 | 550 | 550 | 290 | 340 | 405 |
Max. working pressure | 70Mpa | 35Mpa | 35Mpa | 20Mpa | 70Mpa | 70Mpa | 35Mpa |
