Safety is our culture, quality is our aim.
electric single girder lifting hoist overhead crane
1.Brief introduction of lifting hoist overhead:
electric single girder lifting hoist overhead crane
LD type lifting hoist overhead is characterized by more reasonable structure and higher strength steel as a whole,used together with CD1 model MD1 model electric hoist as a complete set,it is light duty crane with a capacity of 1ton to 20tons. The span is 7.5m-28.5m. Working grade is A3-A4. Working temperature is -25C-40C degree.
There are full field of view cabin suspend under the main girder, there are joint control desk or single control box packed within the Cabin, assemble the sidelong ladder between the Cabin and moving table, The main girder joint with the two side end carriage with the joint point in the middle.
2. Applications of lifting hoist overhead:
electric single girder lifting hoist overhead crane
lifting hoist overhead is widely used in plants,warehouses,material stocks to lift goods. It is prohibited to use the equipment in the combustible,explosive or corrosive environment.
3. Advantage of lifting hoist overhead:
electric single girder lifting hoist overhead crane
1.Reasonable structure and configuration,
2.Favorable performance,
3.Low noise,
4.Commodious cabin with good view,
5.Convenient maintenance and dismantle,
6.Excellent exchangeability for parts and components,
7.Electricity saves,
8.High safety and precision,
9.Starting and stopping smoothly,
10. Favorable price.
4.Control methods of lifting hoist overhead:
electric single girder lifting hoist overhead crane
This lifting hoist overhead has two operational methods,ground or operational room which has open model and closed model can can be installed on left or right side according to the practical intuation. And the direction of entering the gate has two forms,sideway and ends in order to satisfy the users,choice under different conditions.
5.Technical parameters of lifting hoist overhead:
electric single girder lifting hoist overhead crane
capacity |
T | 5 | 10/3 |
16/3 |
20/5 |
32/10 |
||
| Operational method | Pendent line with press button /cabin/remote control | |||||||
| Speed | Main hook Lifting | m/min | 8 ,8/0.8 | 7,7/0.7 | 3.5 | 5 | 5 | |
| Aux. hook Lifting | 8 | 8 | 7 | |||||
| Cross travelling | 20 | 20 | 20 | 20 | 20 | |||
| Long travelling | Ground | 30 | 30 | 30 | 30 | 30 | ||
| Cabin | 60 | 60 | 60 | 60 | 45.75 | |||
| Motor | Lifting | Type /kw | ZD141-4/7.5 | ZD151-4/13/ | ZD151-4/13/ | ZD151-4/13 | ZD162-4/30 | |
| ZD132-4/4.5 | ZD132-4/4.5 | ZD152-4/18.5 | ||||||
| Cross travelling | ZDY122-4/0.8×2 | ZDY122-4/1.5×2 | ZDY122-4/1.5×2 | ZDY122-4/1.5×2 | ZD131-4/3 | |||
| Long travelling | Ground | ZDY122-4/1.5×2 | YZPEY2200-4/2.2×2 | YZPEY2200-4/2.2×2 | ZDDY31M-4/12/2×3.1/1.0 | ZD131-4/3×2 | ||
| Cabin | ZDY122-4/1.5×2 | ZDR112L2-4/3×2 | ZDR112L2-4/3×2 | ZDR112L2-4/3×2 | YZRS114M-4/5×2 | |||
| Electric hoist | Type | CD1/MD1 | CD1/MD1 | CD1/MD1 | CD1/HC | HC | ||
| Lifting height | m | 6,9,12,18,24,30 | 9,12,18,24 | |||||
| Working duty | A5 | |||||||
| Power supply | Adjustable | |||||||
| Span | m | 7.5-22.5 | ||||||
| Recommend rail | 38kg/m | 43kg/m |
||||||
6.Product details show of lifting hoist overhead:
electric single girder lifting hoist overhead crane
7.Installation of lifting hoist overhead:
electric single girder lifting hoist overhead crane
Our delivery is Efficient , Reliable ,and Prompt!
Packaging Detail:
Electrical parts are packed by crate wood,other parts are nude package ,or as client demand.
Delivery Detail:
· If the size is suitable for container ship, usually by container;
· If the size is too big, usually by bulk ship or by container after truncation;
· Transport ways are based on reducing cost for you and keep the crane performance!
According to meet various requirements from customers, we also produce gantry crane , electric flat car , overhead/bridge crane , jib crane , electric hoist ect. If you have any interests in those products , please contect me or scan our wedsite www.kltqz.en.china.cn for more details .
Xinxiang Kailite Crane Equipment Co.,Ltd is a professional lifting equipments exporter with long trading history, having rich technical experience. We are located in Xinxiang--- the crane's hometown, having passed the ISO9001 quality system certification, ISO14001 environmental management system certification and OHSAS18001 occupational health and safety management system certification of enterprise, and CE certification.
Our trademark is "KAILITE", and our company's operation principle is "science and technology innovation, people-oriented". All of our lifting devices and our innovation are built on the basis of the safety of users.
Customer-visits:
Our high quality products and prestige enjoy unanimous favorable comments of customers from America,Pukistan,South Africa,Qatar,Mexico,India,Thailand,Malaysia and so on, they sell well all over the world. You really have a good taste on our products!
1. Is your products customized?
Yes, because the working conditions are different, all our products are customized depending on detail requirement! So if you give us more information about the lift capacity, span, lift height, power source and other specials, we will give you a very quick quote!
2. What’s the information should I provide when inquiry?
Thanks for your question. The more information you provide, the accurate solution we can prepare for you! The information such as the lift capacity, span, lift height, power source or other specials you give us will be more appreciated.
3. How many operating methods for my selection?
Thanks for your question. The standard operating methods we provide is pendent controller with push buttons. Meanwhile, we can also provide the remote control with push buttons and the cabin (space capsule seat) control with joystick. You can choose any of them, just tell us.
4. Do your side can provide other lift tools?
Thanks for your question. Yes, we can provide any kinds of lift tools such as lift, jib crane , grab, overhead crane,flatcar or other specials as your requirement!
You can use our cranes at ease, the best after-sales service will be offered from Kailite.
1, One year warranty for whole machines.
2, Providing free quick-wear part.
3, Low charge for continue maintenance when warranty is expired.
4, Exclusive engineer support at any time.
5, We can provide free training to end-users.
NOTICE
Welcome to sent us email or leave me message to tell me details of lifting hoist overhead demand so that I can sent you offer in shortest time:
- 1. Lifting Capacity?
- 2. Span?
- 3. Lifting height?
- 4. Industry power source in your country?
- 5. Or other detailed requirements?
We Cherish Every Order From Every Customer !
I am jackie, waiting for your contact !
