2.Product Features of overhead bridge crane :
1) Reasonable structure
2) Favorable performance
3) Smooth starting and stopping
4) Safe and reliable traveling
5) Low noise, commodious cabin and good view
6) Convenient maintenance, excellent exchangeability for parts and components
7) Energy saving,reduce energy consumption
8) Using transducer for travelling or traversing crane to realize step speed or stepless speed change
9)Primer and finishing paint
10)Crane structure:steel box type
3.Safety Features of overhead bridge crane :
1)Overloading protection
2)Top quality long time bearing polyurethane materials buffer
3)Crane traveling and cross limit switch
4)Voltage lower protection function, reduce energy consumption
5)Main lifting motor with thermal protection
6)Hooks with latch
7)Rubber buffers
8)Protective earthing
9)Sub-assembly characteristic are tested before assembly
10)Emergency stop system, current over-load protection system, Excellent exchangeability for parts and components
| Capacity(t) | 1t,2t,3t,5t | 10t | 16t |
| Span(m) | 7m---31.5m | ||
| Lifting height(m) | 3m---30m | ||
| Control mode | Pendant control,wireless remote control,cabin control | ||
| Lifting speed(m/min) | 2.8 ,8 , 8/0.8 | 2.3 , 7, 7/0.7 | 4, 4/0.4 |
| Travelling speed(m/min) | 20,30,45 (Inverter) | ||
| Service class(work grade) |
a)A2,A3: used in places of mild service, such as workshop and warehouse. |
||
| b) A4: used in places of Medium service such as assembly and depot. | |||
|
Supply power (three phase power) |
380V 50HZ 3Phase (according to user require) | ||
| Hoist type | Wire rope or chain hoist ,single or double speed | ||
| Working ambient temperature | -20 °C~+45°C. | ||
| Note |
It’s not suitable for lifting blazing & melting metal or toxicant as well as explosion-proof or insulating working conditions. |
||
5.More cranes:
Our delivery is Efficient , Reliable ,and Prompt!
Packaging Detail:
Electrical parts are packed by crate wood,other parts are nude package ,or as client demand.
Delivery Detail:
- If the size is suitable for container ship, usually by container;
- If the size is too big, usually by bulk ship or by container after truncation;
- Transport ways are based on reducing cost for you and keep the crane performance!
Within 15days after the deposit received.
In order to offer you a suitable design and best solution, Please tell us:
1. Is your product customized?
Thanks for your question. Yes, because the working condition are different, all our products are customized
depending on the detail requirement! So if you give us more information about the lift capacity, span, lift height,
power source and other specials, we will give you a very quick quote!
2. What’s the information should I provide when inquiry?
Thanks for your question. The more information you provide, the accurate solution we can prepare for you! The
information such as the lift capacity, span, lift height, power source or other specials you give us will be more
appreciated.
3. How many operating methods for my selection?
Thanks for your question. The standard operating methods we provide is pendent controller with push buttons.
Meanwhile, we can also provide the remote control with push buttons and the cabin (space capsule seat) control
with joystick. You can choose any of them, just tell us!
4. What’s the max lifting capacity of the crane?
Thanks for your question. The max. Lifting capacity of our standard crane are up to 550 ton. If this can’t satisfy
your working requirement. Please contact us for special customized.
5. The space of my workshop is limited, can the crane ok for mine?
Thanks for your question. For low headroom workshop, we have the Special products. The detail dimension please
consult our professional engineer.
6. Can the crane work in hazardous environment?
Thanks for your question.Our product can be divided into two types: one for general manufacturing workshop, the
other for hazardous environment, please consult our professional sales manager for more details.
7. Do your side can provide lift tools?
Thanks for your question. Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet
chuck or other specials as your requirement!
Or other special requirements you tell us would be more appreciated.
Customer Visiting
- Sales manager cell number is 24hours available.
- Payment terms is flexible.
- Design the product according to your technical request.
- Our engineer is willing to help fixing the crane for you.
- Diversity products.
- Delivery on time.
- Warranty: 12 months.
-
Trade Assurance Service.(Trade Assurance is a free payment protection service for buyers.
The service is offered by participating suppliers, and is designed to protect your payment if your order is not shipped on time, or if the pre-shipment product quality (optional) does not match the terms agreed on your contract.
Your payment is protected up to 100% of an amount - agreed between you and the supplier - called the Trade Assurance Order Amount.)
