Following are two models of this automatic rotary die cutter machine :
Model |
HX-320C |
HX-420C |
Slitting Speed |
75m/min |
75m/min |
Die Cutting Speed |
70m/min |
70m/min |
Max Web Width |
Up to 320mm |
Up to 420mm |
Max Unwinding Diameter |
500mm |
500mm |
Max Rewinding Diameter |
480mm |
480mm |
Die cutting length |
178-470mm(7" - 18,5") |
178-470mm(7" - 18,5") |
Overall Diameter |
2100mmx1100mmx1500mm |
2230mmx1320mmx1700mm |
Machine Weight |
1200kgs |
1800kgs |
Power Supply |
220V 50HZ(or according to your requirement) |
220V 50HZ(or according to your requirement) |
HX-320C automatic rotary die cutter machine
allows the production of stamped parts and labels as well as narrow slitted rolls from any roll/reel
material such as paper, foils, adhesive labels/sticker,PVC,PET,protective film, felt pad,etc.
This robust machine consisting of a solid steel frame. The speed can be controlled electronically.
After reaching a preset number of labels or running meters, the machine stops automatically.
Rotary die cutter station:
Die cutting length from 178-470mm(7" - 18,5")
Anvil cylinder
Ability to cut from top or bottom
Adjustable waste rewinder with magnetic powder clutch and 3" air shaft
Standard configurations:
1.One slitting station.
2.One die cutting station
3.With 1pc 3’’ unwinding shaft, 2pcs 3’’ rewinding shafts( the size of shafts can do as your
requirements).
4. With meter/number counter.
5. With two photoelectric eyes
6. With 8 sets of round slitting knives
7.One magnetic brake,two magnetic clutches
8.Machine has blower fan to blow away the trimmed edge
Here are some automatic rotary die cutter machine samples. our machine can die cut any shape you want,only by change the die cutting mould.
1. Q: Are you a factory or trading company?
A: We are a factory and manufacturer
2. Q: Where is your factory located in ? How can I visit there?
A: Our factory is located in Kunshan which is very near from Shanghai, and our detailed
address is: Factory 9, No. 157, Wulian Road, Yushan Town,Kunshan, Suzhou, Jiangsu,
China. If you fly to Shanghai hongqiao airport or Pudong airport, we can pick you up by car from there. We welcome all our clients, home and abroad, to visit us.
3. Q: what are your main products?
A: Our main products are belt cutting machines, slitting machines, sheeting machines,
laminating machines and rotary die cutting machines.
4. Q: Which industries can use your machines ?
A: All industries need to cut (include full cutting and kiss-cutting), slice, laminate, rotary die cut raw materials can use our machines.
