JL-1 Semi-auto Rotary Carton Die Cutting Machine

JL-1 Semi-auto Rotary Carton Die Cutting Machine photo-1
JL-1 Semi-auto Rotary Carton Die Cutting Machine photo-2
JL-1 Semi-auto Rotary Carton Die Cutting Machine photo-3
US$ 5,000 - 5,000 MOQ: 1 Carton
Key Specifications
Get Latest Price
Condition:
New
Function:
Capping, Labeling, Other, Capping, Labeling, die cutter
Application:
Other, Machinery & Hardware
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Function Capping, Labeling, Other, Capping, Labeling, die cutter
Application Other, Machinery & Hardware
Packaging Type Film
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380V
Power 4KW
Place of Origin Hebei, China
Brand Name JIALONG
Model Number JL-1
Dimension(L*W*H) 5000x3500x1500
Certification CE/ISO9001
After-sales Service Provided Engineers available to service machinery overseas

JL-5000 semi-auto rotary carton die cutting machine



 JL-1 semi-auto rotary carton die cutting machine

Machine Introduction
1  Adopt chain feeding paper.
2  Roller adopt automatic equipment transverse moving 40mm.
3  Adopt different speed equipment,automatic adjust upper roller line speed.
4  Grinding-cutting adopt Taiwan splendid gluing boot.
5  Install upper roller automatic repairing function.
6  This machine finished cutting, scorer, cut corner etc function at one time.



Model

MR1300

MR1600

MR1800

MR2000

maximum speed (sheets/min)

60

60

60

60

Working speed (sheets/min)

40

40

40

40

Maximum feed size (mm)

1380x1300

1380x1600

1380x1800

1380x2000

Minimum feed size (mm)

300x500

300x500

300x600

400x600

Thickness of feeding cardboard

3-5 ply

1-8mm

3-5 ply

1-8mm

3-7 ply

1-10mm

3-7 ply

1-10mm

Maximum cutting size (mm)

1380x1200

1380x1500

1380x1700

1380x1900

Main Motor Power (KW)

4.0

5.5

7.5

7.5































 JL-1 semi-auto rotary carton die cutting machineJL-1 semi-auto rotary carton die cutting machineJL-1 semi-auto rotary carton die cutting machine





Company Information

Jialong Packaging Machinery Co.,Ltd  is a academician of Chinese Packaging Technic Association.Our company specializes in discovery, development and production of corrugated cardboard production line, automatic flexo ink printing slotting die cutting machine, semi-autoatic flexo ink printing slotting machine,auto rotary die cutting machine ,single facer corrugator machine, flute laminating machine, automatic carton folder gluer machine,carton stitching machine, slotting machine, thin blade slitter scorer machine, egg tray making machine, paper edge protector making machine, paper tube core making machine and other relevant packaging machinery.

Many years before, our company considers “Quality is first, Honesty is root” as our principal, to meet customers’ demand is our target. We can supply from machine design to after-sale all service with high quality and professional technique.

We would like to cooperate with friend from every countries sincerely, and we will work hard to create the future of package together

JL-1 semi-auto rotary carton die cutting machine





Our Services

After Sales Service
We deeply know that, excellent and effcient after-sales service is an indispensable part for clients to achieve due benefits. To offer most favourable and satisfactory service for wide clients, we hereby solemnly promise:
fessional technicians will be assigned to client's site to give guidance in equipment installation and commissioning and hole training class for operators;we also offer charge-free training in our company for operators and maintenance personnel if requsted by clients.
2.The equipments will be delivered accompanied with detailed installation and operation manual and related information. Upon client's request,we can also offer plant layout design by free of charge.
3.All the equipments are offered with one year quality warranty. within the warranty period, maintenance of equipment and replacement of wearing parts are charge-free.Affer the guarantee is expired, we offer long-term maintenance service and supply of parts and components at cost price. Clinets Complaint: A speacias round-clock fax will receive your complaints seriously. We will response within 24 to 48 hours affer receiving your complaints by phone call or going to site.

our company is professional in this field for more than 15 years,

with the best products and service.

we have all kinds of videos and pictures of our production,

welcom to contact me !
