semi-auto flexo printer rotary die cutter/ corrugated cardboard roller printing slotting carton machine
Performance of the main mechanisms:
Open and closing lf the unit adopts electrical walking and pneumatic locking (with overload protection function).
Paper-feeding roller:The upper axie adopts ginning paper-feeding wheel while the lower axle adopts steel ginning roller.The surface hard chromium-plating guarantees the smooth feeding of the paperboard and does not damage the corruagted cap.
Printing roller,You can adopt the advanced,convenient and practical hanging plate with hooked slots(Optional).Loading and unloading the plate can be independently controlled by the pedal switch.The phase adjusting adopts non-stop-working,360″electrical and numerical adjustment.input the data as per the error.Automaticallyadjust.
Ink circulating system
1The anilox roller adopts the steel material 220 wire or the 220 wire combined anilox roller.
2The rubber roll3er is made up of matural oil proof,acid proof and alkali proot rubber.
3Pneumatic diaphragm pump inking,automatic circulating,Automatic cleaning after adding water.
4Stop working to distribute ink.Stop working and the work lf the ink circulating system for a short time.Cleaning-free to guarantee the quality of the printed things and make the inking color showing no differdnce.
5Pneumatic comtrol lf the anilox and rubber rollers of the ink circulating system.Quick lifting can print more tiny script,fine pattern or color process,It can make the printed matters clear,full and round.
Slotting part(Optional)
1The slotting part can electrically adjust the phase in 360°
2Hand adjust the height of the carton,Four knives are synchronous
2Long and wide adjusting.Loading and unloading the knife disk.Upper and lower creasing.Paper-kicking knife.Creasing shaft.The pointer of the scale can be hand and combinedly moved to save time.(SYK4260,SYK4860 have this function)
Pneumatic and combined control of the whole machine has the function of counting,alarming and operating at the back of the machine.
Four Color Printer Slotter, Four Color Printing Slotting machine
Model |
Size of passing paperboard (mm) |
Printing area |
Power |
Roller diameter |
SDY-1900 |
1800×1470 |
1600×1470mm |
2.2kw |
φ480 |
SDY-2100 |
2000×1470 |
1800×1470mm |
2.2kw |
φ480 |
SDY-2300 |
2200×1470 |
2000×1470mm |
2.2kw |
φ480 |
SDY-2500 |
2400×1600 |
2200×1600mm |
3.0kw |
φ528 |
SDY-2700 |
2600×1600 |
2400×1600mm |
3.0kw |
φ528 |
SDY-2900 |
2800×1600 |
2600×1600mm |
3.0kw |
φ528 |
Jialong Packaging Machinery Co.,Ltd is a academician of Chinese Packaging Technic Association.Our company specializes in discovery, development and production of corrugated cardboard production line, automatic flexo ink printing slotting die cutting machine, semi-autoatic flexo ink printing slotting machine,auto rotary die cutting machine ,single facer corrugator machine, flute laminating machine, automatic carton folder gluer machine,carton stitching machine, slotting machine, thin blade slitter scorer machine, egg tray making machine, paper edge protector making machine, paper tube core making machine and other relevant packaging machinery.
Many years before, our company considers “Quality is first, Honesty is root” as our principal, to meet customers’ demand is our target. We can supply from machine design to after-sale all service with high quality and professional technique.
We would like to cooperate with friend from every countries sincerely, and we will work hard to create the future of package together
After Sales Service
We deeply know that, excellent and effcient after-sales service is an indispensable part for clients to achieve due benefits. To offer most favourable and satisfactory service for wide clients, we hereby solemnly promise:
fessional technicians will be assigned to client's site to give guidance in equipment installation and commissioning and hole training class for operators;we also offer charge-free training in our company for operators and maintenance personnel if requsted by clients.
2.The equipments will be delivered accompanied with detailed installation and operation manual and related information. Upon client's request,we can also offer plant layout design by free of charge.
3.All the equipments are offered with one year quality warranty. within the warranty period, maintenance of equipment and replacement of wearing parts are charge-free.Affer the guarantee is expired, we offer long-term maintenance service and supply of parts and components at cost price. Clinets Complaint: A speacias round-clock fax will receive your complaints seriously. We will response within 24 to 48 hours affer receiving your complaints by phone call or going to site.
