Negotiable
MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
HONG XIANG
Model Number:
M18-M40,PG11-PG36
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HongXiang M18-M40 Factory Price Brass Cable Glands for OutdoorUS$ 1 - 8MOQ: 1 Piece -
PG11-PG36 Waterproof Brass Armoured Cable ConnectorsUS$ 1 - 8MOQ: 1000 Pieces
-
HongXiang PG11-PG36 Cheap Price Flat Brass Cable Wire ConnectorsUS$ 1 - 8MOQ: 1 Piece
-
Flat Hole Cable Gland ,M18-M40,NegotiableMOQ: 1000 Pieces
-
Flat Form Cable Gland ,NPT3/8-NPT1 1/4,CE,ROHSNegotiableMOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
HONG XIANG
Model Number
M18-M40,PG11-PG36
Protection Level
IP68
Size
M18-M40,PG11-PG36
Material
Other, Brass, Brass,nickel plated
Flat cable gland
| CODE | Thread AG | Cable range(mm) | Thread O.D.(mm) | Mounting hole diameter (mm) | Thread length GL(mm) | Spanner size (mm) |
| HX-NPM18F | M18*1.5 | 6*10 | 18 | 18-18.2 | 8 | 20 |
| HX-NPM20AF | M20*1.5 | 5*11.5 | 20 | 20-20.2 | 8 | 22 |
| HX-NPM20BF | M20*1.5 | 6.5*12 | 20 | 20-20.2 | 8 | 22 |
| HX-NPM20CF | M20*1.5 | 6*14 | 20 | 20-20.2 | 8 | 24 |
| HX-NPM20DF | M20*1.5 | 7*12 | 20 | 20-20.2 | 8 | 24 |
| HX-NPM20EF | M20*1.5 | 7*14 | 20 | 20-20.2 | 8 | 24 |
| HX-NPM25AF | M25*1.5 | 6*14 | 25 | 25-25.2 | 9 | 30 |
| HX-NPM25BF | M25*1.5 | 7*14 | 25 | 25-25.2 | 9 | 30 |
| HX-NPM32F | M32*1.5 | 8*22 | 32 | 32-32.2 | 9 | 35 |
| HX-NPM40AF | M40*1.5 | 10*28.5 | 40 | 40-402 | 10 | 50 |
| HX-NPM40BF | M40*1.5 | 5.5*29 | 40 | 40-40.2 | 10 | 50 |
| HX-NPPG11F | PG11 | 6*10 | 18.6 | 18.6-18.8 | 8 | 20/21 |
| HX-NPPG13.5F | PG13.5 | 5*11.5 | 20.4 | 20.4-20.6 | 8 | 22 |
| HX-NPPG16AF | PG16 | 6.5*12 | 22.5 | 22.5-22.7 | 8 | 22 |
| HX-NPPG16BF | PG16 | 6*14 | 22.5 | 22.5-22.7 | 8 | 24 |
| HX-NPPG16CF | PG16 | 7*12 | 22.5 | 22.5-22.7 | 8 | 24 |
| HX-NPPG16DF | PG16 | 7*14 | 22.5 | 22.5-22.7 | 8 | 24 |
| HX-NPPG21AF | PG21 | 6*14 | 28.3 | 28.3-28.5 | 9 | 30 |
| HX-NPPG21BF | PG21 | 7*14 | 28.3 | 29.3-28.5 | 9 | 30 |
| HX-NPPG29F | PG29 | 8*22 | 37 | 37-37.2 | 10 | 40 |
| HX-NPPG36AF | PG36 | 10*28.5 | 47 | 47-47.2 | 10 | 50 |
| HX-NPPG36BF | PG36 | 5.5*29 | 47 | 47-47.2 | 10 | 50 |
