Brass Cable Glands for Armoured Cables

Brass Cable Glands for Armoured Cables thumbnail-1
Brass Cable Glands for Armoured Cables thumbnail-2
Brass Cable Glands for Armoured Cables thumbnail-3
Brass Cable Glands for Armoured Cables thumbnail-4
Brass Cable Glands for Armoured Cables thumbnail-5
Brass Cable Glands for Armoured Cables thumbnail-6
Brass Cable Glands for Armoured Cables photo-1
Brass Cable Glands for Armoured Cables photo-2
Brass Cable Glands for Armoured Cables photo-3
Brass Cable Glands for Armoured Cables photo-4
Brass Cable Glands for Armoured Cables photo-5
Brass Cable Glands for Armoured Cables photo-6
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
HONG XIANG
Model Number:
M12-M100
Contact Supplier Request Quote Chat Now
Yueqing HongXiang Connector Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name HONG XIANG
Model Number M12-M100
Protection Level IP68
Size M12-M100
Material Other, Brass, Brass, nickel plated

brass cable glands for armoured cables

  CODE Thread  AG Cable range(mm) Thread O.D.(mm) Mounting hole diameter (mm) Thread length GL(mm) Joint length H(mm) Spanner size (mm)
HX-NPM12/EMC M12*1.5 6.5-3 12 12-12.2 7 19 14
HX-NPM14/EMC M14*1.5 8-4 14 14-14.2 7 19 17
HX-NPM16/EMC M16*1.5 8-4 16 16-16.2 8 20 18
HX-NPM18/EMC M18*1.5 10-5 18 18-18.2 8 21 20
HX-NPM20/EMC M20*1.5 12-6 20 20-20.2 8 22 22
HX-NPM22/EMC M22*1.5 14-10 22 22-22.2 8 23 24
HX-NPM24/EMC M24*1.5 14-10 24 24-24.2 9 25 24/27
HX-NPM25A/EMC M25*1.5 14-10 25 25-25.2 9 25 24/27
HX-NPM25B/EMC M25*1.5 18-13 25 25-25.2 9 27 30/27
HX-NPM27A/EMC M27*1.5 18-13 27 27-27.2 9 27 30
HX-NPM27B/EMC M27*2 18-13 27 27-27.2 9 27 30
HX-NPM28A/EMC M28*1.5 18-13 28 28-28.2 9 27 30
HX-NPM28B/EMC M28*2 18-13 28 28-28.2 9 27 30
HX-NPM30A/EMC M30*1.5 18-13 30 30-30.2 9 29 30/32
HX-NPM30B/EMC M30*2 18-13 30 30-30.2 9 29 30/32
HX-NPM32A/EMC M32*1.5 22-15 32 32-32.2 10 29 35
HX-NPM32B/EMC M32*2 22-15 32 32-32.2 10 29 35
HX-NPM33A/EMC M33*1.5 22-15 33 33-33.2 10 29 35
HX-NPM33B/EMC M33*2 22-15 33 33-33.2 10 29 35
HX-NPM36A/EMC M36*1.5 25-18 36 36-36.2 10 31 40
HX-NPM36B/EMC M36*2 25-18 36 36-36.2 10 31 40
HX-NPM37A/EMC M37*1.5 25-18 37 37-37.2 10 31 40
HX-NPM37B/EMC M37*2 25-18 37 37-37.2 10 31 40
HX-NPM40A/EMC M40*1.5 25-18 40 40-40.2 11 31 40/45
HX-NPM40B/EMC M40*2 25-18 40 40-40.2 11 31 40/45
HX-NPM40C/EMC M40*1.5 30-22 40 40-40.2 11 35 45
HX-NPM40D/EMC M40*2 30-22 40 40-40.2 11 35 45
HX-NPM42A/EMC M42*1.5 30-22 42 42-42.2 11 35 45
HX-NPM42B/EMC M42*2 30-22 42 42-42.2 11 35 45
HX-NPM47A/EMC M47*1.5 33-25 47 47-47.2 11 37 50
HX-NPM47B/EMC M47*2 33-25 47 47-47.2 11 37 50
HX-NPM48A/EMC M48*1.5 33-25 48 48-48.2 11 37 50/52
HX-NPM48B/EMC M48*2 33-25 48 48-48.2 11 37 50/52
HX-NPM50A/EMC M50*1.5 38-32 50 50-50.2 12 37 50/55
HX-NPM50B/EMC M50*2 38-32 50 50-50.2 12 37 50/55
HX-NPM54A/EMC M54*1.5 38-32 54 54-54.2 12 38 57
HX-NPM54B/EMC M54*2 38-32 54 54-54.2 12 38 57
HX-NPM56A/EMC M56*1.5 38-32 56 56-56.2 12 38 57/59
HX-NPM56B/EMC M56*2 38-32 56 56-56.2 12 38 57/59
HX-NPM60A/EMC M60*1.5 44-37 60 60-60.2 13 38 64
HX-NPM60B/EMC M60*2 44-37 60 60-60.2 13 38 64
HX-NPM63A/EMC M63*1.5 44-37 63 63-63.2 13 38 64/68
HX-NPM63B/EMC M63*2 44-37 63 63-63.2 13 38 64/68
HX-NPM64A/EMC M64*1.5 44-37 64 64-64.2 13 38 64/68
HX-NPM64B/EMC M64*2 44-37 64 64-64.2 13 38 64/68
HX-NPM72/EMC M72*2 52-42 72 72-72.2 15 42 77
HX-NPM75/EMC M75*2 52-42 75 75-75.2 15 42 77
HX-NPM80/EMC M80*2 62-55 80 80-80.2 15 45 88
HX-NPM88/EMC M88*2 70-65 88 88-88.2 15 45 94
HX-NPM100/EMC M100*2 84-78 100 100-100.2 15 45 110



brass cable glands for armoured cables
