Hot Sales Semi-auto Flute Laminater

Hot Sales Semi-auto Flute Laminater photo-1
Hot Sales Semi-auto Flute Laminater photo-2
Hot Sales Semi-auto Flute Laminater photo-3
Hot Sales Semi-auto Flute Laminater photo-4
US$ 9,000 - 9,000 MOQ: 1 Carton
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Film
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Film
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380V
Power 6kw
Place of Origin Hebei, China
Brand Name JIALONG
Model Number JL-1
Dimension(L*W*H) 8800x1950x1500
Weight 3000kg
Certification CE ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Hot sales semi-auto flute laminaterHot sales semi-auto flute laminaterHot sales semi-auto flute laminaterHot sales semi-auto flute laminater






Major feature



1. Feeding of high table, automatic feeding for bottom sheet, elastic front register, simple operation.

2. just need one person to feed the paper. It has low request to paper, suitable for laminating paperboard to bottom paperboard, ABCDE Flute corrugated cardboard. Even filmed paper can be laminated.

3. Top sheet forwarded by manual on high table and the sheet can be piled up to 1.8m.

4. Bottom sheet is automatically fed; the two sheets are piled freely; High efficiency
5. Advanced elastic front register is used for location, high register precision, bottom paper will never exceed. When laminating, it is very easy to make top paper and bottom paper alignment, or top sheet exceeded.
6. Fully automatic glue supply system: glue will be automatically supplied during lamination, and recovered, avoiding glue wasted.
7. Scientific design for linear speed of metering roller, avoiding glue thrown when high-speed running.
7. The whole machine adopts PLC control system, compared with other time-delay device or middle relay control, the bottom paper is transferred more precise and stable, furthermore, speed is greatly increased, and circiut breakdown can automatically display and alarm.
8. Clean the lower roller in gluing section by blade with circulated water, complete cleaning, convenient to replace the blade
9. Floating movable pressing section is adopted to make the laminated paperboard smooth. This section can be moved front and back to take in paper conveniently.

10.. Gear rach is used to control the lift of water tray, which is easily taken out for cleaning.





Technological parameter:

Model

HRBTMJ-1300H

HRBTMJ-1500H

HRBTMJ-1600H

Max size of cover face

1300mmX1250mm

1500mmX1250mm

1600mmX1250mm

Mix size of cover face

360mmX360mm

360mmX360mm

360mmX360mm

Economic speed



0-80 piece/min

0-80 piece/min

0-80 piece/min

Precision



+-1

+-1

+-1

Power



6kw

6kw

6kw

Size



8.8m x 1.95m x 1.5m

8.8m x 2.15m x 1.5m

8.8m x 2.25m x 1.5m

Weight



About 3T

About 3T

About 3T





Company Information

Jialong Packaging Machinery Co.,Ltd  is a academician of Chinese Packaging Technic Association.Our company specializes in discovery, development and production of corrugated cardboard production line, automatic flexo ink printing slotting die cutting machine, semi-autoatic flexo ink printing slotting machine,auto rotary die cutting machine ,single facer corrugator machine, flute laminating machine, automatic carton folder gluer machine,carton stitching machine, slotting machine, thin blade slitter scorer machine, egg tray making machine, paper edge protector making machine, paper tube core making machine and other relevant packaging machinery.

Many years before, our company considers “Quality is first, Honesty is root” as our principal, to meet customers’ demand is our target. We can supply from machine design to after-sale all service with high quality and professional technique.

We would like to cooperate with friend from every countries sincerely, and we will work hard to create the future of package together

Hot sales semi-auto flute laminater



Packaging & Shipping

 Hot sales semi-auto flute laminaterHot sales semi-auto flute laminater



Our Services

After Sales Service
We deeply know that, excellent and effcient after-sales service is an indispensable part for clients to achieve due benefits. To offer most favourable and satisfactory service for wide clients, we hereby solemnly promise:
fessional technicians will be assigned to client's site to give guidance in equipment installation and commissioning and hole training class for operators;we also offer charge-free training in our company for operators and maintenance personnel if requsted by clients.
2.The equipments will be delivered accompanied with detailed installation and operation manual and related information. Upon client's request,we can also offer plant layout design by free of charge.
3.All the equipments are offered with one year quality warranty. within the warranty period, maintenance of equipment and replacement of wearing parts are charge-free.Affer the guarantee is expired, we offer long-term maintenance service and supply of parts and components at cost price. Clinets Complaint: A speacias round-clock fax will receive your complaints seriously. We will response within 24 to 48 hours affer receiving your complaints by phone call or going to site.

Hot sales semi-auto flute laminater



Hot sales semi-auto flute laminater
