Factory supply 7.5t electric hoist
- 500 Set / Sets per Month
- QINGDAO;SHANGHAI;TIANJIN;AND ANY PORT IN CHINA
- T/T Credit Card PayPal
- cheap wire rope wireless remote control 250kg electric hoist
- building material remote control mini electric hoist
- Factory supply electric hoist,hoist small cranes
- Factory supply electric wire rope hoist, 3 ton hoist
- 10ton mini wire hoist crane, hoist electric lift
- cd electric wire rope lifting hoist crane 2 ton
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | KLT CRANE |
Model Number: | CD1/MD1 | Usage: | Construction Hoist | Power Source: | Electric |
Sling Type: | Wire Rope | Maximum Lifting Weight: | 32t | Maximum Lifting Height: | 30m |
Lift Speed: | 8m/min | Certification: | CE;ISO;UV | Warranty: | 12months |
After-sales Service Provided: | Overseas third-party support available |
Product Description
CD1/MD1 7.5t electric hoist :
It's small lifting equipment with tight structure, small volume and light weight.Widely common use and convenient operation. It keeps a long life and high efficiency when reducers with hard gear surface adopted.
Conic rotor brake motor are equipped, which has safety limit device in both up and down directions.
CD model with general speed can satisfy common lifting;
MD model has two lifting speed :general speed and slow speed, Work with slow speed can realize precision loading and unloading, such as examine and machine repair and similar precision work.
Applications of 7.5t electric hoist :
The electric hoists common used in industrial and mine enterprises, railway, wharves and warehouses.which can be mounted on single beam,overhead cranes,gantry and jib cranes.it is widely used in factories,mines,harbors,warehouse,cargo store areas and shops etc.
Control method of 7.5t electric hoist :
Pendent press button and wireless remote control .(you can choose one or both)
2.Product Features of 7.5t electric hoist :
1) Reasonable structure
2) Favorable performance
3) Smooth starting and stopping
4) Safe and reliable traveling
5) Low noise, commodious cabin and good view
6) Convenient maintenance, excellent exchangeability for parts and components
7) Energy saving,reduce energy consumption
8) Using transducer for travelling or traversing crane to realize step speed or stepless speed change
9)Primer and finishing paint
3.Safety Features of 7.5t electric hoist :
1)Overloading protection
2)Top quality long time bearing polyurethane materials buffer
3)Voltage lower protection function, reduce energy consumption
4)Emergency stop system, current over-load protection system, excellent exchangeability for parts and components
7.5t electric hoist | ||||
Lift capacity (t) | Lift speed (m/min) | Travel speed (m/min) | lift height (m) | Work duty |
0.25 | 8 0.8/8 | 20 | 3,6,9 | A3/A5 |
0.5 | 8 0.8/8 | 20/30 | 6,9,12 | |
1 | 8 0.8/8 | 20/30 | 6,9,12,18,24,30 | |
2 | 8 0.8/8 | 20/30 | 6,9,12,18,24,30 | |
3 | 8 0.8/8 | 20/30 | 6,9,12,18,24,30 | |
5 | 8 0.8/8 | 20/30 | 6,9,12,18,24,30 | |
10 | 7 0.7/7 | 20/30 | 9,12,18,24,30 | |
16 | 3.5 0.35/3.5 | 18 | 9,12,18 | |
20 | 4 | 20 | 9,12,18 |
5.More hoists:
Our delivery is Efficient , Reliable ,and Prompt!
Packaging Detail:
Electrical parts are packed by crate wood,other parts are nude package ,or as client demand.
Delivery Detail:
- If the size is suitable for container ship, usually by container;
- If the size is too big, usually by bulk ship or by container after truncation;
- Transport ways are based on reducing cost for you and keep the crane performance!
Within 10 working days after the deposit received.
In order to offer you a suitable design and best solution, Please tell us:
- Kinds of product you need?
- Working condition. Which material to lift? Temperature?
- Load capacity?
- Lifting height?
Or other special requirements you tell us would be more appreciated.
Customer Visiting
- Sales manager cell number is 24hours available.
- Payment terms is flexible.
- Design the product according to your technical request.
- Our engineer is willing to help fixing the crane for you.
- Diversity products.
- Delivery on time.
- Warranty: 12 months.
- Trade Assurance Service.(Trade Assurance is a free payment protection service for buyers.
The service is offered by participating suppliers, and is designed to protect your payment if your order is not shipped on time, or if the pre-shipment product quality (optional) does not match the terms agreed on your contract.
Your payment is protected up to 100% of an amount - agreed between you and the supplier - called the Trade Assurance Order Amount.)
If you have any interest in our products or any questions,
please do not hesitate to contact me. I will help you to know
more about our products' detail.
Contact Us
- Xinxiang Kailite Crane Equipment Co., Ltd.
- Contact nameJane Sun Chat Now
- Phone86-0373-7013556,7013557
- AddressDistrict 3, Jiankang Road, Weibin District, Xinxiang City Xinxiang,Henan
