500mW rs232 Wireless Data Transmitter
- 10000 Piece / Pieces per Month
- shenzhen
- Credit Card
- Hik Compatible Mstar Chipset 5MP 3.6mm Fixed Lens Human Detection Waterproof Turret IP Camera
- Hik Copatible NDAA 5MP Mstar Focal Lens(2.8-12mm) Human Detection Dome Surveillance IP Camera
- Hot Selling 16CH Face Capture 8G RAM Hik Compatible 6 USB Ports NVR
- Hikon's Best Alternative NDAA Human Detection Remote View Bullet 5MP IP66 Surveillance Camera
- Hik Compatible CCTV 5MP Focal Lens( 2.8-12mm) Human Detection Bullet IP66 Surveillance Camera H. 264 & H. 265
- Hik Compatible H.264 & H.265 IP66 Bullet Surveillance Camera 5MP Fixed lens 2.88mm Human detection
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Safe Guard | Model Number: | SG-500 |
Product Description
Specifications
1. Power: 500mW (default), 600mW~1W (optional).2. Frequency: 433MHz (default), 400-470MHz, 868MHz, 915MHz (optional)
500mW rs232 Wireless Data Transceiver
Instruction:
SG-500 is a kind of low power wireless transceiver data module with small size, low power consumption as well as good stability and reliability, it is widely used as wireless data transceiver in long-ranges, narrowband low power UHF wireless data transmitters and receivers with channel spacing as low as 25 KHz.
Features:
1. Power: 500mW (default), 600mW~1W (optional).
2. Frequency: 433MHz (default), 400-470MHz, 868MHz, 915MHz (optional)
3. High anti- interference and Low BER (Bit Error Rate)
Based on GFSK modulation, high-efficiency forward error correction channel encoding technology is used to ensure the data’s resistance against both transient interference and random interference. The actual BER can be achieved to 10-5~ 10-6 when channel BER is 10-2.
4. Long Transmission Distance
Within the visible range, when the height of antenna is higher than 2m and the BER is 10-3, the reliable transmission distance is 3000m @1200bps and 2000m@9600bps respectively.
5. Transparent data transmission
Transparent data interface used in transceivers is to satisfy many standard and nonstandard user protocols. Any false data generated in air can be filtrated automatically (What has been received is exactly what has been transmitted).
6. Multi-channels
SG-500 provides 8 channels, expandable for 16, 32 channels according to requirements of users.
7. Three connection methods with DB9 connector
SG-500 transceiver provides DB9 connector with three connections: a non-standard RS-232 port and a non-standard RS-485 port. USB interface port is also available. It can get power from PC directly.
8. Big data buffer area
With optional interface baud rates: 1200/4800/9600/19200bps and 8N1/8E1/8O1 data format (decide by user), the transceiver can transmit unlimited data frames with flexible user program.
Note: the RF data rate is only settled down before delivery; please specify our sales your requirements when placing your orders.
9. Intelligent data control system and no other extra programs required
Even for half duplex communication, no other excessive programs are required. All RF system data transmission/reception and other On-the-Fly conversion and control are performed by SG-500 transceiver automatically.
10. Lower power consumption & nice sleep function
With +5V power, the receiving current is less than 25mA, the transmitting current is less than 300mA, and the sleeping current is less than 20uA.
11. High reliability, small size and excellent performance
By using monolithic radio-frequency integrated circuit and single-chip MCU, the transceivers have less peripheral circuits, high reliability, and low failure rate.
12. Various options for configurable antennas.
13. Watchdog monitor inside
Watchdog monitors the inner operation, so it can change the traditional product structure and also improve the reliability of our modules.
14. Beautiful metal shell.
Technical specification:
* Modulation mode: GFSK/FSK
* Working frequency: 400MHz~470MHz;
* Power supply: DC 5V (7.5V~12V is available, specify when placing the order);
* RF power: ≤500mW, 600mW~1W is available;
* RF data rate: 1200/2400/4800/9600/19200bps (Set before delivery);
* Receive current: <28mA (TTL connect);
* Receive sensitivity: -123dBm (1200bps); -118dBm (9600bps);
* Transmitting current: <350mA;
* Sleep current: <20uA;
* Interface data format: 8E1/8N1/8O1;
* Working humidity: 10%~90% relative humidity without condensation;
* Working temperature: -40°C~+80°C (industrial standard)
* RF Line-of-sight Range: 2km (BER=10-5@9600bps);
3km (BER=10-5@1200bps);
* Size: 80*45*20mm (without antenna port).
Application:
* Automatic Meter Reading (AMR);
* Wireless alarm and security systems;
* Building automation, security systems, wireless monitor, remote control and access control system;
* Wireless data transmission, automatic data collection system;
* Radio modem can be used for Sports training & competition;
* Wireless dishes ordering;
* Wireless POS, PDA wireless smart terminal;
* RF module can be used for electronic bus station and intelligent traffics;
* RF transmitter, Wireless electronic display screen and Queuing machine;
* Wireless telemetry; charging for parking, parking lot;
* Wireless modem automobile inspection and four-wheel orientation;
* Wireless sensor, Industrial wireless remote control and air conditioning remote controller;
* Data communication in the aspects of railway, oil field, dock and army.
* LED display in thruway and public place;
* Point to multi-point wireless network, wireless on-the-spot bus and automatic data collection system
Installation dimension:
