12W IP68 / 316 Stainless Steel RGB LED Underwater Light
HG-P38U-9*1W / HG-P38U-12*1W
Top View |
Front View |
|
|
Back View |
Single Color |
|
|
|
RGB |
Dimension |
|
|
12W/ IP68/ 316 Stainless Steel RGB LED Underwater Light
Main parameters:
Specification |
Parameter |
Model No. |
HG-P38U-12*1W |
LED Qty. |
12 pcs 1W High power |
Input Voltage |
AC/DC 12V |
Input Frequency |
50-60 Hz |
Power |
13±1 W(W/G/B/RGB) 8±1 W(red) |
Luminous flux |
780±10%Lm(P.W) 750±10%Lm(W.W) 700±10%Lm(C.W) 280±10%(R) / 520±10%(G) 120±10%(B) /350±10%(RGB) |
|
Wave Length (RGB) |
R:620-630 K/nm G:515-525 K/nm B:460-470 K/nm |
Color temperature |
p.w.6000~7000k w.w.:3000-3500k c.w.8000~10000k |
Dimension |
176mm(diameter) x 108mm(height) |
Working temperature |
-20~50℃ |
Storage Temperature |
-20~50℃ |
Base |
wire |
Constant driver |
yes |
IP rating |
IP68 |
|
Constant driver & over-current protection |
yes |
Features:
l 316 (V4A) stainless steel LED underwater light, unique heat-dissipation & waterproof design,
high-grade and artistic, wide application.
l Transparent PC cover, anti-corrosion, shock-proof, unbreakable, safe transportation
l IP68 structure waterproof
l high power 1w as light source, Epistar, Bridgelux, Epileds as led chip for options.
l Color: Red, Green, Blue, RGB, 14 kinds of color changing mode
Single color – white, red, green, blue, yellow
l 5 kinds of RGB control method: Remote control, Wi-Fi Control, DMX Control,
Automatic control, External control (wire control)
l Constant driver to make sure LED light working stable, avoid any flashing and noisy
l Life span: >30000 hours
l Over-current protection
Applications: garden pond, square, water column, flower-bed in villas, garden, rocky water-fall, outdoor fountain, etc.
|
|
|
Installation diagram:
Packaging:
1 pc in a white box, 30 pcs in a 75x32x35cm master carton N.W.: 22 kgs
it also can be customized based on the customers' requirements.
Shipping:
7-15 working days, it also depends on your order quantity.
OEM or ODM
Our advanced production lines, precise equipment, strict quality control process and experienced
engineer team are capable to fulfill the toughest OEM or ODM requirement from customers worldwide.
M.O.Q.
Generally, we don’t require M.O.Q. in order to help some clients to expand their business & keep the
ball rolling.
Lead time
7-15 working days based on stock material and order quantity.
Payment
T/T, Western Union or LC(at sight)
Incoterms
EX-Factory/work, FOB, CIF
Warranty
All our products are covered by 24 months warranty from the date of purchase
We are not responsible for any damage caused by improper use/assembling or force majeure.
SHENZHEN HEGUANG LIGHTING CO., LTD. is a sophisticated manufacturer which specializes in R&D
and production of LED Light ODM & OEM in fields of LED Swimming Pool Light and Underwater Light as well as Fountain Light, Wall Washer, etc.
If you are interested in the IP68 / 316 Stainless Steel /LED Underwater Light , please feel free to contact us.
