Single-turn Potentiometer
US$ 3 - 15
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
OMTER
Model Number:
R.W-1
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Carbon Potentiometer 0.5w PotentiometersUS$ 1 - 25MOQ: 100 Pieces -
F-17S Carbon Potentiometer With SwitchUS$ 0.3 - 5MOQ: 1000 Pieces
-
Aluminum Alloy Housing Precision PotentiometerUS$ 15 - 22MOQ: 1 Pint
-
Switch PotentiometerUS$ 2 - 6MOQ: 1000 Pieces
-
20mm Slide PotentiometerUS$ 2 - 10MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
OMTER
Model Number
R.W-1
Type
Rotary Potentiometer
Technology
Wirewound
Resistance
10ohm to 100Kohm
Resistance Tolerance
+ 10 % Standard, + 5 % special
Rated Power
3 Watt @ 40 ° C
Max. Operating Voltage
250 VDC
Operating Temperature
/
Specifications
Single-turn potentiometerResistance Range:10 W to 100K W
Resistance Tolerance + 10 % Standard, + 5 % special
single-turn potentiometer
Resistance Range |
10ohm to 100Kohm |
Standard #118alues |
10,25,50,100,150,200,250,500, |
Resistance Tolerance |
+ 10 % Standard, + 5 % special |
Power Ratting |
3 Watt @ 40 ° C |
End Resistance |
0.2 W or 0.02 % which ever is > |
Effective Angle of Rot. |
265° + 15° |
Maximum Working Vol. |
250 VDC |
Insulation Resistance |
200 Meg. W @ 500 VDC |
Voltage Proof |
1000 VAC for 1 Min. At Sea level |
TCR of Resistance Wire |
150 ppm/ ° C |
Mechanical Angle of Rot. |
285° + 15° |
Rotational Life Expectancy |
20,000 Cycles |
Temperature Range |
0 - 70° C |
...
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2006
Factory Size
3,000-5,000 square meters
Total Employees
11 - 50 People
