2016 Hot Sale New Designed Portable Foam Generator :
1 Application And Features :
Concrete foaming heat insulation plate production line, through many years’ experience in the production of foam
concrete, refers to large foam concrete board production line configuration, optimize formulations, with advanced equipment, develop a new generation of foam concrete slab production line.
Reliable technology, small investment, construction period is short, can get rapid gains;
The main raw materials: cement, foaming agents, which is common and easy to get;
Production way is flexible, easy to implement; social and economic benefits are very significant.
1.1 Simple structure, convenient operation, small footprint, easy transition.
1.2 Mixer automatic feeding, reduce the work of workers; direction control system can effectively control of the direction of mixer; slurry discharge system can effectively solute congestion of discharge.
1.3 Mixing system with precise measurement,can mix the slurry evenly,does not harm the bulbs,can finish stirring a pot of feed with 2 to 3 minutes, high production efficiency.
1.4 Cutting unit equips with advanced power control systems, inverter controls the speed of material feeding, effectively control the yield and quality, easy to operate. Cutting system uses a reciprocating motion system, high cutting accuracy and quick speed.
1.5 Mold uses sub-structure, precise size, easy disassembly.
Technical Parameters Of Different Models :
5 m³ per hour capacity 100A (small portable type) :
| Model | 100A |
| Voltage | Customized |
| Pumping Work Way | Peristaltic Hose Pump |
| Hose Pump Power | 4KW |
| Piston Pump Power | 3KW |
| Air Pump Power | 4KW |
| Production Capacity | 5 M3/Hour |
| Vertical Conveying Height | 30 M |
| Level Conveying Distance | 100 M |
| By particle size | ≤1.5 CM |
| High Pressure | 2.0 Mpa |
| Outlet pressure | 1.5 Mpa |
| Dimensions (L * W * H) | 1500*900*900 mm |
| Foaming Pumping Machine | 280 Kg |
| (Main Machine) Weight | |
| Total Weight | 500 Kg |
101A
Model | 101A |
Voltage | 380 V |
Power | 4 KW |
Output | 10-12 M3/h |
Vertical Conveying Height | 60 M |
Level Conveying Distance | 600 M |
Particle Size | ≤1.5 CM |
Max Pressure | 2.0 Mpa |
Outlet pressure | 1.5 Mpa |
Dimensions (L * W * H) | 1500*900*900 mm |
Weight | 480 Kg |
Total Weight | 960 Kg |
102A
Model | 102A |
Voltage | 380 V |
Power | 5.5 KW |
output | 15-20 M3/h |
Vertical Conveying Height | 100 M |
Level Conveying Distance | 600 M |
Particle Size | ≤1.5 CM |
Max Pressure | 2.0 Mpa |
Outlet Pressure | 1.5 Mpa |
Dimensions (L * W * H) | 1500*880*1380 mm |
Weight | 500 Kg |
Total Weight | 980 Kg |
102B
Model | 102B |
Voltage | 380 V |
Power | 7.5 KW |
output | 25-30 M3/h |
Vertical Conveying Height | 120 M |
Level Conveying Distance | 1000 M |
Particle Size | ≤1.5 CM |
Max Pressure | 2.0 Mpa |
Outlet Pressure | 1.5 Mpa |
Dimensions (L * W * H) | 1700*880*1380 mm |
Weight | 600 Kg |
Total Weight | 1080 Kg |
102C
Model | 102C |
Voltage | 380 V |
Power | 11 KW |
output | 50-60 M3/h |
Vertical Conveying Height | 80 M |
Level Conveying Distance | 800 M |
Particle Size | ≤1.5 CM |
Max Pressure | 2.0 Mpa |
Outlet Pressure | 1.5 Mpa |
Dimensions (L * W * H) | 1950*880*1380 mm |
Weight | 700 Kg |
Total Weight | 1180 Kg |
You can produce different types of bricks/blocks by pouring the foaming concrete to different moulds :
Here are brick moulds :
Here are block moulds :
Here are wall panel moulds :
Here is construction for pouring insulation floor layer :
| Related Products |
1 Foaming Concrete Brick And Block Machine
2 Foaming Agent |
| 1 How about the quality of machines? |
| Our machines adopt advanced technology. Moreover, we carry out strict supervision during production and make sure every finished product with high quality. |
| 2 About the delivery time. |
| Generally, it will be about 20-25 days days after your deposit, which also will be on basis of your order. |
| 3 About warranty. |
| We provide 12 months for warranty. |
| 4 Which kind of payment is available for us? |
| T/T, L/C and Western Union are common for us. |
| 5 How about the service? |
| Provide overseas installation, debugging and training the relating work . |
Shipped in one 20ft container
