TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay

TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-1
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-2
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-3
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-4
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-5
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay thumbnail-6
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-1
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-2
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-3
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-4
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-5
TIWIN 60W 5400lm Roes Red Body Pure White LED High Bay photo-6
Negotiable MOQ: 1 Carton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
3535
Warranty(Years):
3
Input Voltage(V):
220-240V
Contact Supplier Request Quote Chat Now
Jiangsu Tianying Opto-Electronics Technology Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 3535
Warranty(Years) 3
Input Voltage(V) 220-240V
Lamp Power(W) 60
Lamp Luminous Flux(lm) 5400
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Pure White
Working Temperature(℃) -20, 45
Working Lifetime(Hour) 40000
Lamp Body Material Aluminum
IP Rating Other, IP20
Certification CCC
Place of Origin Jiangsu, China
Brand Name TIWIN
Model Number BYME2003A3U-S540RD3N500



Product Description

 TIWIN 60W 5400lm Rose red  body pure white LED high bay



CCT:4000K   60°

 Watt:60W/80W/100W/120W

Lumen:5400lm/7200lm/9000lm/10800lm

Chips: Cree 27pcs/35pcs/45pcs/54pcs

Body color: Dark grey/Silver grey/Rose red/Apple green/Lemon yellow



Features:
Using spinning aluminum shell, good heat dissipation
CREE brand LED chips, quality guaranteed
Optical lenses
Lifetime up to 40,000 hours
Colors: dark gray, silver grey, rose red, apple green, lemon yellow to suit different applications
Warranty: 2 years
Part No.  Description
Φ300 × H215 mm, 60 Watt, 220-240VAC,Ra≥70,IP20,  ≥40000H
BYME-60W-NW-DG BYME2003A3U-S540DG3N500

60 Watt,27pcs CREE, 4000K, 5400lm, 60°,

dark grey, 2 years warranty
BYME-60W-NW-SG BYME2003A3U-S540SG3N500

60 Watt,27pcs CREE, 4000K, 5400lm, 60°,

silver grey, 2 years warranty
BYME-60W-NW-RR BYME2003A3U-S540RD3N500

60 Watt,27pcs CREE, 4000K, 5400lm, 60°,

 rose red, 2 years warranty
BYME-60W-NW-AG BYME2003A3U-S540GN3N500

60 Watt,27pcs CREE, 4000K, 5400lm, 60°,

apple green, 2 years warranty
BYME-60W-NW-LY BYME2003A3U-S540GY3N500

27pcs CREE, 4000K, 5400lm, 60°,

lemon yellow, 2 years warranty
Φ300 × H215 mm, 80 Watt, 220-240VAC,Ra≥70,IP20,  ≥40000H
BYME-80W-NW-DG BYME2004A3U-S540DG3N500

80 Watt,35pcs CREE, 4000K, 7200lm, 60°,

dark grey, 2 years warranty
BYME-80W-NW-SG BYME2004A3U-S540SG3N500

80 Watt,35pcs CREE, 4000K, 7200lm, 60°,

silver grey, 2 years warranty
BYME-80W-NW-RR BYME2004A3U-S540RD3N500

80 Watt,35pcs CREE, 4000K, 7200lm, 60°,

 rose red, 2 years warranty
BYME-80W-NW-AG BYME2004A3U-S540GN3N500

80 Watt,35pcs CREE, 4000K, 7200lm, 60°,

apple green, 2 years warranty
BYME-80W-NW-LY BYME2004A3U-S540GY3N500

80 Watt,35pcs CREE, 4000K, 7200lm, 60°,

 lemon yellow, 2 years warranty
Φ300 × H215 mm, 100 Watt, 220-240VAC,Ra≥70,IP20,  ≥40000H
BYME-100W-NW-DG BYME2005A3U-S540DG3N500

100 Watt,45pcs CREE, 4000K, 9000lm, 60°,

dark grey, 2 years warranty
BYME-100W-NW-SG BYME2005A3U-S540SG3N500

100 Watt,45pcs CREE, 4000K, 9000lm, 60°,

 silver grey, 2 years warranty
BYME-100W-NW-RR BYME2005A3U-S540RD3N500

100 Watt,45pcs CREE, 4000K, 9000lm, 60°,

 rose red, 2 years warranty
BYME-100W-NW-AG BYME2005A3U-S540GN3N500

100 Watt,45pcs CREE, 4000K, 9000lm, 60°,

 apple green, 2 years warranty
BYME-100W-NW-LY BYME2005A3U-S540GY3N500

100 Watt,45pcs CREE, 4000K, 9000lm, 60°,

 lemon yellow, 2 years warranty
Φ300 × H215 mm, 120 Watt, 220-240VAC,Ra≥70,IP20,  ≥40000H
BYME-120W-NW-DG BYME2006A3U-S540DG3N500

120 Watt,54pcs CREE, 4000K, 10800lm, 60°,

 dark grey, 2 years warranty
BYME-120W-NW-SG BYME2006A3U-S540SG3N500

120 Watt,54pcs CREE, 4000K, 10800lm, 60°,

 silver grey, 2 years warranty
BYME-120W-NW-RR BYME2006A3U-S540RD3N500

120 Watt,54pcs CREE, 4000K, 10800lm, 60°,

 rose red, 2 years warranty
BYME-120W-NW-AG BYME2006A3U-S540GN3N500

120 Watt,54pcs CREE, 4000K, 10800lm, 60°,

 apple green, 2 years warranty
BYME-120W-NW-LY BYME2006A3U-S540GY3N500

120 Watt,54pcs CREE, 4000K, 10800lm, 60°,

 lemon yellow, 2 years warranty



Specification:



 TIWIN 60W 5400lm Rose red  body pure white LED high bay



TIWIN 60W 5400lm Roes red body pure white LED high bay JIANGSU TIWIN OPTO-ELECTRONICS TECHNOLOGY CO.,LTD.
Document ID   Product Specification Version 1.01
Compile Date   Page 2014/1/1
Photo TIWIN 60W 5400lm Roes red body pure white LED high bay Item
Name BYME Highbay
Product specification 220-240VAC, 50-60Hz  60W/80W/100W/120W
Size Φ300 × H215mm
Installation method Pendant Mounted
  dimensions  TIWIN 60W 5400lm Roes red body pure white LED high bay ambient temperature  -15-40℃,10%~65% RH
Angle adjustment No
Control method No
IP grade IP20
Rated lifespan ≥40000H
standard GB7000.1-2007
material aluminum alloy
Radiator component aluminum alloy
Ottica
Installations component install ring
 color dark grey/Silver gray/red/green/yellow
CPD   Beam angle 60°
Luminous flux

5400±80lm/7200±120lm/

9000±160lm/10800±200lm
CCT 4500±500K
CRI Ra≥70
Brand CREE
Lamp type
specification 27/36/45/54pcs
specification
Inner box size 350×350×190mm
Carton size
weight(Kg) N.W =4/4.2/4.4/4.5kg
packing 1pcs per carton



 Pictures:

TIWIN 60W 5400lm Roes red body pure white LED high bay

TIWIN 60W 5400lm Roes red body pure white LED high bay

TIWIN 60W 5400lm Roes red body pure white LED high bayTIWIN 60W 5400lm Roes red body pure white LED high bay

TIWIN 60W 5400lm Roes red body pure white LED high bay
