Help CenterTIWIN 60W 5400lm Apple Green Body Pure White LED High Bay
Related Products
-
TIWIN 80W 7200lm Apple Green Body Pure White LED High BayNegotiableMOQ: 1 Carton -
TIWIN 80W 7200lm Lemon Yellow Body Pure White LED High BayNegotiableMOQ: 1 Carton
-
TIWIN 80W 7200lm Lemon Yellow Body Pure White LED High BayNegotiableMOQ: 1 Carton
-
TIWIN 80W 7200lm Silver Grey Body Pure White LED High BayNegotiableMOQ: 1 Carton
-
TIWIN 80W 7200lm Dark Grey Body Pure White LED High BayNegotiableMOQ: 1 Carton
TIWIN 60W 5400lm Apple green body pure white LED high bay
CCT:4000K 60°
Watt:60W/80W/100W/120W
Lumen:5400lm/7200lm/9000lm/10800lm
Chips: Cree 27pcs/35pcs/45pcs/54pcs
Body color: Dark grey/Silver grey/Rose red/Apple green/Lemon yellow
| Features: | ||
| Using spinning aluminum shell, good heat dissipation CREE brand LED chips, quality guaranteed Optical lenses Lifetime up to 40,000 hours Colors: dark gray, silver grey, rose red, apple green, lemon yellow to suit different applications Warranty: 2 years | ||
| Part No. | Description | |
| Φ300 × H215 mm, 60 Watt, 220-240VAC,Ra≥70,IP20, ≥40000H | ||
| BYME-60W-NW-DG | BYME2003A3U-S540DG3N500 | 60 Watt,27pcs CREE, 4000K, 5400lm, 60°, dark grey, 2 years warranty |
| BYME-60W-NW-SG | BYME2003A3U-S540SG3N500 | 60 Watt,27pcs CREE, 4000K, 5400lm, 60°, silver grey, 2 years warranty |
| BYME-60W-NW-RR | BYME2003A3U-S540RD3N500 | 60 Watt,27pcs CREE, 4000K, 5400lm, 60°, rose red, 2 years warranty |
| BYME-60W-NW-AG | BYME2003A3U-S540GN3N500 | 60 Watt,27pcs CREE, 4000K, 5400lm, 60°, apple green, 2 years warranty |
| BYME-60W-NW-LY | BYME2003A3U-S540GY3N500 | 27pcs CREE, 4000K, 5400lm, 60°, lemon yellow, 2 years warranty |
| Φ300 × H215 mm, 80 Watt, 220-240VAC,Ra≥70,IP20, ≥40000H | ||
| BYME-80W-NW-DG | BYME2004A3U-S540DG3N500 | 80 Watt,35pcs CREE, 4000K, 7200lm, 60°, dark grey, 2 years warranty |
| BYME-80W-NW-SG | BYME2004A3U-S540SG3N500 | 80 Watt,35pcs CREE, 4000K, 7200lm, 60°, silver grey, 2 years warranty |
| BYME-80W-NW-RR | BYME2004A3U-S540RD3N500 | 80 Watt,35pcs CREE, 4000K, 7200lm, 60°, rose red, 2 years warranty |
| BYME-80W-NW-AG | BYME2004A3U-S540GN3N500 | 80 Watt,35pcs CREE, 4000K, 7200lm, 60°, apple green, 2 years warranty |
| BYME-80W-NW-LY | BYME2004A3U-S540GY3N500 | 80 Watt,35pcs CREE, 4000K, 7200lm, 60°, lemon yellow, 2 years warranty |
| Φ300 × H215 mm, 100 Watt, 220-240VAC,Ra≥70,IP20, ≥40000H | ||
| BYME-100W-NW-DG | BYME2005A3U-S540DG3N500 | 100 Watt,45pcs CREE, 4000K, 9000lm, 60°, dark grey, 2 years warranty |
| BYME-100W-NW-SG | BYME2005A3U-S540SG3N500 | 100 Watt,45pcs CREE, 4000K, 9000lm, 60°, silver grey, 2 years warranty |
| BYME-100W-NW-RR | BYME2005A3U-S540RD3N500 | 100 Watt,45pcs CREE, 4000K, 9000lm, 60°, rose red, 2 years warranty |
| BYME-100W-NW-AG | BYME2005A3U-S540GN3N500 | 100 Watt,45pcs CREE, 4000K, 9000lm, 60°, apple green, 2 years warranty |
| BYME-100W-NW-LY | BYME2005A3U-S540GY3N500 | 100 Watt,45pcs CREE, 4000K, 9000lm, 60°, lemon yellow, 2 years warranty |
| Φ300 × H215 mm, 120 Watt, 220-240VAC,Ra≥70,IP20, ≥40000H | ||
| BYME-120W-NW-DG | BYME2006A3U-S540DG3N500 | 120 Watt,54pcs CREE, 4000K, 10800lm, 60°, dark grey, 2 years warranty |
| BYME-120W-NW-SG | BYME2006A3U-S540SG3N500 | 120 Watt,54pcs CREE, 4000K, 10800lm, 60°, silver grey, 2 years warranty |
| BYME-120W-NW-RR | BYME2006A3U-S540RD3N500 | 120 Watt,54pcs CREE, 4000K, 10800lm, 60°, rose red, 2 years warranty |
| BYME-120W-NW-AG | BYME2006A3U-S540GN3N500 | 120 Watt,54pcs CREE, 4000K, 10800lm, 60°, apple green, 2 years warranty |
| BYME-120W-NW-LY | BYME2006A3U-S540GY3N500 | 120 Watt,54pcs CREE, 4000K, 10800lm, 60°, lemon yellow, 2 years warranty |
Specification:
TIWIN 60W 5400lm Apple green body pure white LED high bay
| JIANGSU TIWIN OPTO-ELECTRONICS TECHNOLOGY CO.,LTD. | ||||||
| Document ID | Product Specification | Version | 1.01 | ||||
| Compile Date | Page | 2014/1/1 | |||||
| Photo | | Item | |||||
| Name | BYME Highbay | ||||||
| Product specification | 220-240VAC, 50-60Hz 60W/80W/100W/120W | ||||||
| Size | Φ300 × H215mm | ||||||
| Installation method | Pendant Mounted | ||||||
| dimensions | | ambient temperature | -15-40℃,10%~65% RH | ||||
| Angle adjustment | No | ||||||
| Control method | No | ||||||
| IP grade | IP20 | ||||||
| Rated lifespan | ≥40000H | ||||||
| standard | GB7000.1-2007 | ||||||
| material | aluminum alloy | ||||||
| Radiator component | aluminum alloy | ||||||
| Ottica | |||||||
| Installations component | install ring | ||||||
| color | dark grey/Silver gray/red/green/yellow | ||||||
| CPD | Beam angle | 60° | |||||
| Luminous flux | 5400±80lm/7200±120lm/ 9000±160lm/10800±200lm | ||||||
| CCT | 4500±500K | ||||||
| CRI | Ra≥70 | ||||||
| Brand | CREE | ||||||
| Lamp type | |||||||
| specification | 27/36/45/54pcs | ||||||
| specification | |||||||
| Inner box size | 350×350×190mm | ||||||
| Carton size | |||||||
| weight(Kg) | N.W =4/4.2/4.4/4.5kg | ||||||
| packing | 1pcs per carton | ||||||
