Factory Direct Induction Heating Machine (JLCG-30KW)

FOB Price

USD $10,000 - $20,000 / Set

1 Set(Min.Order)

Supply Ability 3000 Set / Sets per Month
Port Shenzhen/Guangzhou/Hongkong
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Jinlai
Model Number	JLCG-30KW	Voltage	380AV
Current	45A	Rated Capacity	100%
Rated Duty Cycle	100%	Weight	100KG
Usage	welding,brazing,heat treatment	Certification	CE,ISO9001:2008
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Factory Direct Induction Heating Machine
1.High frequency,heat dia:0.1mm workpiece
2.Fault protection
3.Easy operation

Factory Direct Induction Heating Machine

Product Description

Main feature

1. Ultrahigh series: High frequency, able to heatΦ 0.1mm workpiece

2. Small size, light weight, low failure rate and conservation of energy (which can save the power by 70% as compared with glass-ceramic vacuum tube high frequency heating machines).

3. It can ensure the solid welding point which is pleasing and delicate in appearance, integral geometric configuration, perfect surface grain, complete crystal structure of internal metal part, limited annealing range and elimination of obvious weld knot.

4. About ten types fault protection and display of over-current, over-voltage, water shortage and phase missing can provide higher reliability and durability.

5. It is applied to the welding of couplers and inserts used in metal glass manufacturing as well as electric appliance and electronics industries, non-contact welding of internal parts of small-size relays, high-pressure refrigerating parts, headwear decorations, metal ornamental articles and art wares.

Specification:

Model		JLCG-30KW
Input power desire		3 phase 380V 50/60HZ
Oscillate power max		30KW
Max input current		45A
Oscillate frequency		50-200KHZ
Cooling water desire		0.3Mpa≥6L/MIN
Duty cycle		100% 40°C
Dimensions	Generator	630300540mm
	Transformer	450300430mm
Net weight		30kg/20kg
Cable length		2-6(Meters)

Applications:

Particulary designed for small precision pieces soldering,quenching,heating.

1. Harden treatment for belt of saw,knife.

2. Harden treatment for both sides belt of knife.

3. Quenching valves.

4. Heating electrod.

5. Brazing of the saw tip.

6. Quenching of the gear.

7. Heating of the small scren.

8. Drills forging or hardening.

9. Brazing of the small PCB drills.

10. Brazing for parts of jewellery.

11. Brazing for parts of artware.

12. Brazing for the parts of optical spectacle frame.

13. Soldering for DLC data link connector.

14. Tin-Lead bonding Antennas.

15. Tin soldering Coaxial Cable.

16. Annealing the small parts.

17. Brazing of the tools.

18. Quenching of the small shaft.

19. Shaping of the small shaft.
