Special Rectifier Transformer Of Medium Frequency Induction Furnace

Special Rectifier Transformer Of Medium Frequency Induction Furnace thumbnail-1
Special Rectifier Transformer Of Medium Frequency Induction Furnace photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Jinlai
Model Number:
JL
Contact Supplier Request Quote Chat Now
Dongguan Jinlai Electromechanical Device Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Jinlai
Model Number JL
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Special Rectifier Transformer Of Medium Frequency Induction Furnace
1.high efficiency
2.high overload ability

Special Rectifier Transformer Of Medium Frequency Induction Furnace







Product Description

 Overview & Application



Electric furnace transformer is refers to the power transformer of industrial furnace melting , it is a special transformer which is designed according to the working characteristic and operation mode of medium frequency electric furnace.





Feature

  • outstanding characteristic: designed according to the national industry standards and the different electric furnace process, energy saving, environmental protection, prevent harmonic, no fever, resistance to short-circuit, high overload ability.
  • Compared with the conventional transformer with the same capacity, melting time shortened about 20%, tons of power consumption dropped about 70 degrees.It can saving electricity about 210000 degrees each year as Annual output calculated at 3000 tons
  • The special transformer is suitable for the medium frequency furnace which capacity is below 30 tons . High side voltage is 10 kv and 35 kv. low side voltage is divided into: 400 v, 660 v, 750 v, 850 v, 950 v, 1000 v, 1100 v, 1250 v and 1500 v.It has two structure: with electric reactor and without electric reactor, and also has large impedance and small impedance to meet the needs of the use

 Main Technical Parameters:



model voltage on line side(KW) direct power parameters
rectifier system floating voltage
(V)		 working current
(A)		 equal No.
of phase		 join group lable
ZPS-630/10 10 three-phase bridge 540 1114 6 D/yn11
ZPS-800/10 10 three-phase bridge 540 1415 6 D/yn11
ZPS-1000/10 10 double three-phase bridge 776 1230 6 D/yn11
ZPS-1250/10 10 double three-phase bridge 776 1570 12 D/do-yn11
ZPS-1500/10 10 double three-phase bridge 776 1846 12 D/do-yn11
ZPS-1800/10 10 double three-phase bridge 776 2215 12 Y/d11-yn0
ZPS-2000/10 10 double three-phase bridge 776 2460 12 D/do-yn11
ZPS-2500/10 10 double three-phase bridge 776 3076 12 D/do-yn11
ZPS-3000/10 10 double three-phase bridge 891 3216 12 D/do-yn11
ZPS-3600/10 10 double three-phase bridge 891 3860 12 Y/d11-yn0
ZPS-5000/10 10 double three-phase bridge 891 5400 12 D/do-yn11
ZPS-7000/10 35 double three-phase bridge 1050 4720 12 Y/d11-yn0
ZPS-8000/10 35 double three-phase bridge 1050 5394 12 Y/d11-yn0
