Help CenterRotor Heat Cooperation Medium Frequency Induction Heating Machine
Related Products
Specifications
Rotor Heat Cooperation Medium Frequency Induction Heating Machine1.Fast heating.
2.Widely applicable.
3.Low power consumptio
Rotor Heat Cooperation Medium Frequency Induction Heating Machine
Main Specifications:
Model |
JLZ-15 |
Input power max |
15KW |
Input power desire |
3 phase 380V 50/60HZ |
Fluctuating frequency |
1— 20KHZ |
Heating current |
3--22A |
Output voltage |
70-550V |
Duty cycle |
100%24hours work |
Weight |
21KG |
Cooling water desire |
>0.2MPa 3L/Min |
Additional function of JLZ-15 with timer |
(1) Heating time: 0.1— 99.9 sec. |
Main Characteristics:
2. High efficiency, low power consumption, easy installation and simple operation.
3. It can continuously work for 24 hours for the comprehensive full load design.
4. It adopts the IGBT inverter circuit in parallel connection, which has high load adaptability.
5. It has functions as overvoltage, over-current, overheat, phase loss and water shortage alarm indications as automatic control and protection.
6. Compared with other heating modes, it can significantly promote the economic benefits, improve the quality of heated work pieces, save the energy and material, alleviate labor intensity and improve the production environment.
Our Jinlai Induction Heating Machine is divided into four series according to output frequency:
1) Medium Frequency Series(JLZ): 1KHZ-20KHZ
2) Ultrasonic Frequency Series (JLC) : 10KHZ-30KHZ
3) High Frequency Series (JL) : 30KHZ-100KHZ
4) Ultrahigh Frequency (JLCG) : 100KHZ-1.1MHZ
