TIWIN 36W LED Tube Curved Batten

Name: TIWIN 36W LED Tube Curved Batten
Brand: TIWIN
SKU: 123721107
Availability: InStock

Negotiable MOQ: 8 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

TIWIN

Model Number:

CR030036A8U-N065SG4D101

Jiangsu Tianying Opto-Electronics Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name TIWIN

Model Number CR030036A8U-N065SG4D101

TIWIN 36W LED tube Curved Batten

According to square pass installation structure design, does not destroy the ceiling structure, make the whole lighting space harmonious

Applications: modern offices, commercial places, trains and subway tunnels, etc.

2-years warranty

Features

According to square pass installation structure design, luminous arc tube combined with the perfect ceiling

High-quality aluminum light body, good heat dissipation

Light cover is made of light diffusion PC, soft and even light

CREE/CITILED brand LED chip and driver, stable performance

Variety of installation mode, no dark areas in serie

	JIANGSU TIWIN OPTO-ELECTRONICS TECHNOLOGY CO.,LTD.
Document ID	Product Specification			Version	1.01
Compile Date				Page	1/1
Pho t o		Category	Item	Specifications
		Lamp Info.	Name	Luminous arc tube
			Model	SLS3702 A36
			Product code	CR030036A8U-N030SG4D101
			Product specification	AC220V 50Hz 36W
			Size	L1177 x W120 x H80 mm
			Installation method	Ceiling-mounted
			ambient temperature	-10~40℃@20~85%
			Angle adjustment	No
			Control method	No
			Protection grade	IP20
			Rated lifespan	≥30000H
dimensions		standard	standard	GB7000.1-2007
			certification	CCC
		Major component	material	Aluminum profile
			Radiator component	PCB panel+ aluminum lamp body
			Ottica	Light diffusion PC(milky white)
			Installations component	Snap-in
			color	Alumina ecru
CPD		Optical parameters	Beam angle	140°
			Luminous flux	3300±160LM
			CCT	6000±500K
			CRI	Ra≥70
		Light source	Brand	Epistar
			Lamp type	SMD3014
			specification	0.1W ,360pcs8
attachment		Electric appliance	Brand	TIWIN
			name	Built-in LED driver
			specification	Output 36W 90mA constant current drive
			IP	--
		Packing	Inner box size	K3A 3 layers undetermined
			Carton size	A=B five layers undetermined
			Enclosure	Installation instructions accessories bag
			packing	8 inner boxes per carton
