Home > Lights & Lighting > LED Interior Lighting > LED Tube > TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar

Name: TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar
Brand: TIWIN
SKU: 123721047
Availability: InStock

Jiangsu Tianying Opto-Electronics Technology Company Limited

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar thumbnail-1

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar thumbnail-2

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar thumbnail-3

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar thumbnail-4

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar photo-1

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar photo-2

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar photo-3

TIWIN New Style Indoor Led Light Epistar Chip Curved Batten 36w Led Bar photo-4

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

LED Light Source:

EPISTAR, CREE

Warranty(Years):

Input Voltage(V):

220-240

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source EPISTAR, CREE

Warranty(Years) 2

Input Voltage(V) 220-240

Lamp Power(W) 36

Lamp Luminous Flux(lm) 3500

Lamp Luminous Efficiency(lm/w) 89

Color Temperature(CCT) Other, 6000k

Working Temperature(℃) -10, 40

Working Lifetime(Hour) 30000

Lamp Body Material PVC

IP Rating Other, IP20

Certification CCC, CE, CQC, Energy Star

Place of Origin Jiangsu, China

Brand Name TIWIN

Model Number Other, LED SQUARE TUBE

Specifications

TIWIN new style indoor led light Epistar chip 36w led bar Curved Batten
well-known brand LED chip luminous source,

TIWIN new style indoor led light Epistar chip Curved Batten 36w led bar

Applications: modern offices, commercial places, trains and subway tunnels, etc.

2-years warranty

Features

According to square pass installation structure design, luminous arc tube combined with the perfect ceiling

High-quality aluminum light body, good heat dissipation

Light cover is made of light diffusion PC, soft and even light

brand LED chip and driver, stable performance

Variety of installation mode, no dark areas in serie

CR03 serie

Working environment

Installation

Protection grade

Color

CCT

Beam angle

Rated life

Input voltage

-10~+40℃

buckle

IP 20

Aluminum

6000K

140°

30000h

220-240V/50-60Hz

Specifications

MODEL#	Dimensions	Power of lamp	Luminous flux	Power efficiency	Power factor	CRI	Electrical protection	Package number
CR030036A8U	117712080mm	36W	3500LM	>90%	>0.9	>70	Class I	8PCS/box

Company Introduction

IV. Production capability

TIWIN owns automated production lines, production equipment and instruments, including 9 SMT production lines, 65 sets equipments, such as: automatic wave soldering, reflow soldering, automatic braiding, automatic optical spectral machines and other production equipments..

We own 41 assembly lines, with more than 185 sets automatic printing machine, glue machine, burn-in machine and waterproof IP67/68/65 test equipments.
