Full Range Metal Scrap Induction Melting Furnace
US$ 1,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Jinlai
Model Number:
JL-KGPS-1.0Ton
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MF Series Induction Melting Furnace MachineUS$ 1,000 - 100,000MOQ: 1 Set -
Electrical Power Induction Furnace Melting DeviceUS$ 1,000 - 100,000MOQ: 1 Set
-
Complete Set Electric Iron Melting FurnaceUS$ 1,000 - 100,000MOQ: 1 Set
-
Electric Iron Melting Furnace For Melting Iron Scrap/Cast IronUS$ 1,000 - 100,000MOQ: 1 Set
-
Ethiopia Hot Sale Steel Smelting Induction FurnaceUS$ 1,000 - 100,000MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Jinlai
Model Number
JL-KGPS-1.0Ton
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Full Range Metal Scrap Induction Melting Furnace1.high efficiency
2.easy operation, safety
3.energy saving
Full Range Metal Scrap Induction Melting Furnace
Product Description
Overview and Application:
Medium frequency induction melting furnace is the device converting three phase power current into single phase intermediate frequency current and enabling metal to produce eddy current loss through electromagnetic field induction to achieve heating and melting. It’s applicable to melting, heating or holding of steel, copper, aluminum, zinc, tin, nickel sliver and other ferrous or nonferrous metal and alloy material, as well as heating treatment prior to forging, sintering and tube-bending forming in casting and melting industries.
Performance and features:
- Zero-voltage scanning soft start, start or stop at any time under any state without impact on power supply;
- Rapidly melting, low production cost, low pollution, conforming to environmental protection requirement;
- Melting directly from low temperature, available for fully emptying of solution, easy change of melting material;
- Flexibly adjustable power, easy and continuous smooth adjustment, easily controllable temperature, low oxidization loss, uniform metal content;
- Furnace shell with cast aluminum ally or steel construction, small footprint, easy overturn body, available for selection of electric, manual, hydraulic or other overturn mode as needed;
- Adapt angle of the inverter automatic adjustment circuit design, automatically match the load impedance, keep the equipment running in good working condition without adjusting the compensation capacitance, automatically diagnose error and easy to maintenance.
Technical Parameter:
| Rate Power | 800KW | Furnace Temperature | 1800°C |
| Input Voltage | 380V | Melting Rate | 1ton/h |
| Phase | 3 | Furnace Capacity | 1Ton |
| Input Current | 1280A | Power consumption per ton | 340-600KW/T |
| DC Current | 1600A | Cooling water flower rate | 10-30T/H |
| DC Voltage | 500V | Cooling water pressure | 0.15MPa≤P≤0.25 Mpa |
| IF Voltage | 750V | Input water temperature | >40°C |
| Input Frequency | 50HZ | Temperature Rise | >20°C |
| IF Frequency | 0.7-1KHZ | Cooling water flower rate | 10-30T/H |
