Specifications
WiFi RepeaterNo longer to change Source AP into WDS. Simply put Repeater's SSID to expand wireless coverage.Traditional APs Conventions
The Source AP MUST be changed to WDS Repeating Mode as same as the Repeating
Why WAB-2401 ?
Not necessary to change any setting of the source AP. Just put the Repeater’s SSID (and security key if requested), then it will automatic to connect to the Source AP and immediately to expand the wireless coverage
Specification: |
|
Standard Compliance |
IEEE 802.11b/g/n standard |
Antenna |
1 Dipole Antenna (1 x1) |
Ethernet |
1 10/100Base-Tx |
Frequency Range |
2.400GHz~2.4835GHz |
Operating Cannel |
2.412~2.462GHz(Canada,FCC)/ 11 Channels |
|
2.412~2.484GHz(Japan,TELEC)/ 14 Channels |
|
2.412~2.472GHz(Euro,ETSI) / 13 Channels |
Modulation Technique |
Orthogonal frequency division multiplexing (OFDM) |
|
Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK) |
Security |
64/128bit WEP, WPA, WPA2, 802.1x and 802.11i |
Media Access Protocol |
CSMA/CA with ACK |
Output Power |
802.11b : 25 ± 1 dBm |
(Average) |
802.11g : 23 ± 1 dBm |
|
802.11n : 23 ± 1 dBm |
Data Rate |
11n : 300/270/240/180/120/90/60144.4/120/115.6/86.7/57.8/43.4/ 28.9/14.4 Mbps |
11g : 54/48/38/24/18/6 Mbps with auto-rate fall back |
|
|
11b : 12/11/9/5.5/2/1 Mbps with auto-rate fall back |
Sensitivity |
-74 dBm @54Mbps |
-89 dBm @11Mbps |
|
-70 dBm @11n (20MHz) |
|
|
-66 dBm @11n (40MHz) |
Power adapter |
DC 12V /1.0A |
Operating Temperature |
0~55°C ambient temperature |
Storage Temperature |
(-20)~70°C ambient temperature |
Humidity |
5%~90% |
Operating System Support |
Windows 98SE/ME/2000/XP/Vista, MAC OS 10.4.8 Linux |
Approval |
FCC Part 15 & CE |
Dimension |
170 x 113 x 26 mm |
Weight |
200g |
