Part number: POE-USP-8012NN8
Description: The PoE-USP series of Splitter is an 80W output of ultra Power over Ethernet (PoE) Splitter. Working with MITS 100W ultra PoE Injector, POE-UIJ-HD56NN8 will be an ideal solution for Ethernet terminal devices that need ultra power under 80W
Application
- For PDs which need ultra power (<80W).
RJ45 Connector and Pin-out
| RJ-45 Input (Data & Power) | RJ-45 Output (Data Only) | ||||
| Pin | Symbol | Description | Pin | Symbol | Description |
| 1 | BI_DA+, Vin A+/ | Data Pair A+, Feeding power A+/ | 1 | BI_DA+ | Data Pair A+ |
| 2 | BI_DA-, Vin A+/- | Data Pair A-, Feeding power A+/- | 2 | BI_DA- | Data Pair A- |
| 3 | BI_DB+, Vin A+/- | Data Pair B+, Feeding power A+/- | 3 | BI_DB+ | Data Pair B+ |
| 4 | BI_DC+, Vin B+/- | Data Pair C+, Feeding power B+/- | 4 | BI_DC+ | Data Pair C+ |
| 5 | BI_DC-, Vin B+/- | Data Pair C-, Feeding power B+/- | 5 | BI_DC- | Data Pair C- |
| 6 | BI_DB-, Vin A+/- | Data Pair B-, Feeding power A+/- | 6 | BI_DB- | Data Pair B- |
| 7 | BI_DD+, Vin B+/- | Data Pair D+, Feeding power B+/- | 7 | BI_DD+ | Data Pair D+ |
| 8 | BI_DD-, Vin B+/- | Data Pair D+, Feeding power B+/ | 8 | BI_DD- | Data Pair D- |
| 9 | Shield | Connector shielding | 9 | Shield | Connector shielding |
Note : 1. DC output and Vin+/- should not be shorted to ground(FG).
>>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>
Mechanical & Dimension
Plastic Case Material |
PC |
Plastic Case Finish |
Texture |
Plastic Case Color |
Black |
Plastic Case Dimension |
150 x 140 x 40 (L x W x |
Package
| Number of unit in one Carton | 20 |
| Weight of Carton Volume | N.W.:7Kg. G.W.:8Kg. 1.8Cuft. |
| Dimension of Box | 267 x 160 x 45 (L x W x H) mm |
