17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices

17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-1
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-2
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-3
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-4
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-5
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-6
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-1
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-2
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-3
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-4
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-5
17W/48V 1 Port DC Input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-6
US$ 51 - 93 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
MITS
Model Number:
POE-IC-1748IDN
Contact Supplier Request Quote Chat Now
MITS COMPONENT & SYSTEM CORP.
Payment & Shipping
Payment Methods:
Port of Shipment:
TPE
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name MITS
Model Number POE-IC-1748IDN
Product Description

 17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices

Part number:   POE-IC-1748IDN

Description:  17W/48V output,  with IEEE 802.3af detection



Application

  • IP Phone
  • IP Camera
  • Access Point
  • Door Security
  • Security CAM
  • Any network terminals which work with industrial DC input system
  • Network terminals which require power under 24W



    RJ-45 Input (Data Only)

    RJ-45 Output (Data & Power)

    Pin

    Symbol

    Description

    Symbol

    Description

    1

    Rx+

    Data Receive

    Rx+

    Data Receive

    2

    Rx-

    Data Receive

    Rx-

    Data Receive

    3

    Tx+

    Data Transmit

    Tx+

    Data Transmit

    4

    NC

    Not Connected

    -Vdc

    Feeding power(+)

    5

    NC

    Not Connected

    -Vdc

    Feeding power(+)

    6

    Tx-

    Data Transmit

    Tx-

    Data Transmit

    7

    NC

    Not Connected

    -Vdc_return(+)

    Feeding power(-)

    8

    NC

    Not Connected

    -Vdc_return(+)

    Feeding power(-)

    >>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking DevicesContact us now >>>>

Packaging & Shipping



Mechanical & Dimension

Plastic Case Material

PC

Plastic Case Finish

Texture

Plastic Case Color

Gray

Plastic Case Dimension

86 x 76 x 36 (L x W x H) mm.

 Package

Number of unit in one Carton

100

Weight and Volume without Power cord

N.W.:17Kg. G.W.:18Kg. 1.9Cuft.

White Box Dimension

120 x 85 x 40 (L x W x H) mm

Power cord Package

N.W.:15Kg. G.W.:16Kg. 1.3Cuft.





17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices





We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or ocean shipment.



Accept small, trial orders, and costomised orders too!

Our Services



Please note: All of our product's delivery term is: Ex-work Taiwan, the FOB pricing is for reference only
If there is any product information needed, please contact us or consult online17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices





 17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices>>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>



Company Information



MITS is a Taiwanese Company has more than 20 years of trading experiences with clients all over the world.

Any kind of customizing product projects are welcome. Please feel free to contact us for product details.

17W/48V 1 port DC input PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices
