18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices

18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-1
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-2
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-3
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-4
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-5
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices thumbnail-6
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-1
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-2
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-3
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-4
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-5
18W/18V 1 Port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices photo-6
US$ 25 - 60 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
MITS
Model Number:
POE-IJ-1818NNN
Contact Supplier Request Quote Chat Now
MITS COMPONENT & SYSTEM CORP.
Payment & Shipping
Payment Methods:
Port of Shipment:
TPE
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name MITS
Model Number POE-IJ-1818NNN
Product Description



18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices

Part number:    POE-IJ-1818NNN

Description:  18W/18V output, No optional function



Application



  • IP Phone
  • IP Camera
  • Access Point
  • Door Security
  • Security CAM
  • Network terminals which require power under 24W

RJ-45 Connector and Pin-Out



RJ-45 Input (Data Only)

RJ-45 Output (Data & Power)

Pin

Symbol

Description

Symbol

Description

1

Rx+

Data Receive

Rx+

Data Receive

2

Rx-

Data Receive

Rx-

Data Receive

3

Tx+

Data Transmit

Tx+

Data Transmit

4

NC

Not Connected

-Vdc_return(+)

Feeding power(+)

5

NC

Not Connected

-Vdc_return(+)

Feeding power(+)

6

Tx-

Data Transmit

Tx-

Data Transmit

7

NC

Not Connected

-V dc

Feeding power(-)

8

NC

Not Connected

-V dc

Feeding power(-)






18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices>>>" href="https://img13.fr-trading.com/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>
Packaging & Shipping



Mechanical & Dimension

Plastic Case Material

PC

Plastic Case Finish

Texture

Plastic Case Color

Gray

Plastic Case Dimension

85 x 78 x 36 (L x W x H) mm.



Package

Number of unit in one Carton

100

Weight and Volume without Power cord

N.W.:17Kg. G.W.:18Kg. 1.9Cuft.

White Box Dimension

120 x 85 x 40 (L x W x H) mm

Power cord Package

N.W.:15Kg. G.W.:16Kg. 1.3Cuft.


18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices



We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or oceanshipment.

Accept small, trial orders, and costomised orders too!

Our Services



Please note: All of our product's delivery term is: Ex-work Taiwan, the FOB pricing is for reference only
If there is any product information needed, please contact us or consult online18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices



18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices>>>" href="https://img13.fr-trading.com/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>

Company Information



MITS is a Taiwanese Company has more than 20 years of trading experiences with clients all over the world.

Any kind of customizing product projects are welcome. Please feel free to contact us for product details.18W/18V 1 port PoE Injector for IP Phone, IP Cam, AP, Security & Networking Devices
