The PoE PSE-SW8G Switch family provides 7 Gigabit ports with PoE with PSE function + 1 Gigabit up-link port with PoE PD function. It allows the data and power to travel 200 meters instead of 100 meter follwing Ethernet standards.
In the LTPoE++ model, the PoE PSE delivers power up to 70W/port to a PD. The LTPoE++ is Linear Technology Corporation’s specification. This specification provides detection and classification extensions to existing IEEE PoE protocols. It is backward compatible with IEEE 802.3af and 802.3at as well.
Hardware Description
There are 18 LEDs on the PoE switch to indicate the status of power and signal. The following sectioin describes the functions of each LED indicator
Front panel detail
Model Information
Specification
