5 Zone Amplifier

5 Zone Amplifier thumbnail-1
5 Zone Amplifier photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
PATECH
Model Number:
QSM-624AZ
Type:
Professional Amplifier
Contact Supplier Request Quote Chat Now
Pa Tech Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name PATECH
Model Number QSM-624AZ
Type Professional Amplifier
Channels 1
Place of Origin Taiwan, China

Specifications

QSM-624AZ
INPUT :3MIC 3AUX
OUTPUT:100V 70V 8HOM PRE REC OUT 5 ZONE
MIC1 PRIORYTY
POWER SUPPLY:AC 115/230V 50/60HZ DC:24V



Model

QSM-606AZ

QSM-612AZ

QSM-624AZ

Power Output (RMS)

60W

120W

240W

Power Supply

AC 115/230V 50/60Hz,DC 24V

Total Harmonic Distortion

<=1%@1 KHz

Sensitivity

1/4" Phone Jack (Unbalance)
Channel 1~3(Mic 1~3) 0.5mV@600 ohm
Phone Jack 2mV@50k ohm
Channel 4(Mic 4) 0.5mV@600 ohm
Aux 1 100mV@220K ohm
Channel 5(Aux 2), Aux 3 100mV@10k ohm

Output

100V, 70V, 8 ohm

Signal to Noise Ratio

86dB

Tone

Bass 100 Hz +/-10 dB
Treble 10 KHz +/-10 dB

AC Power Consumption

(@ RATED POWER)

160W

320W

640W

DC Power Consumption

(@ RATED POWER)

4A

8A

15A

Dimension

88(H) x 425(W) x 305mm (D)
Weight

8.2 kgs

8.7 kgs

11.5 kgs

Gross Weight

11.2 kgs

11.7 kgs

14.5 KGS

Mounting

FREE STANDING OR 19" RACK
