Product Description
Standard |
Grade |
C max |
Mn max |
Si max |
P |
S |
Yield strength max mpa |
Tensile strength mpa |
Elongation% |
ASTM A333 |
GR.1 |
0.30 |
0.40-1.06 |
--- |
0.025 |
0.025 |
205 |
380 |
20-25 |
ASTM A333 |
GR.3 |
0.19 |
0.31-0.64 |
0.18-0.37 |
0.025 |
0.025 |
240 |
450 |
14-20 |
ASTM A333 |
GR.4 |
0.12 |
0.50-1.05 |
0.08-0.37 |
0.025 |
0.025 |
240 |
415 |
12-17 |
ASTM A333 |
GR.6 |
0.30 |
0.29-1.06 |
0.10 |
0.025 |
0.025 |
240 |
415 |
14-22 |
ASTM A333 |
GR.7 |
0.19 |
0.90 |
0.13-0.32 |
0.025 |
0.025 |
240 |
450 |
28 |
ASTM A333 |
GR.8 |
0.13 |
0.90 |
0.13-0.32 |
0.025 |
0.025 |
515 |
619 |
22 |
ASTM A333 |
GR.9 |
0.20 |
0.40-1.06 |
- |
0.025 |
0.025 |
315 |
435 |
18 |
ASTM A333 |
GR.10 |
0.20 |
1.15-1.50 |
0.10-0.35 |
0.025 |
0.025 |
450 |
550 |
18 |
ASTM A333 |
GR.11 |
0.10 |
0.60 |
0.35 |
0.025 |
0.025 |
240 |
450 |
18 |
Steel Pipe Materials Can Be Supplied
| item | material | standard | specification (OD*WT)mm | usage |
| alloy pipe | Cr5Mo. 15CrMo | GB5310-95 GB9948-88 | 16-824*2-100 | The seamless steal pipes features resistance to high pressure, high/low temperature and corrosion and is used in the industries of petroleum, chemical engineering and. Electric power as well as boiler |
| 13CrMo44 | ASTMA335/A335M | |||
| 12Cr1MoV P22 | ASTMA213/213M | |||
| T91,P91,P9, | DIN17175-79 | |||
| T9 Wb36 | JISG3467-88 | |||
| JISG3458-88 | ||||
| High-pressure boiler pipe | 20G,A106, | GB5310-95 | 14-630*2-80 | Temperature-resistant seamless steel pipe far high-pressure boiler |
| ST 45 | ASTM A 106-99 | |||
| DIN17175-79 | ||||
| Seamless pipes for petroleum | 20, 12CrMo, | GB9948-88 | 10-530*1.5-36 | Boiler pipes for refinery, heat-exchanging pipes,seamless steel pipes for pipeline |
| 15CrMo | ||||
| High-pressure Seamless pipes for fertilizer making equipment | 20, 16Mn, | GB6479-2000 | 18-530*3-40 | Fertilizer making equipment and pipe line |
| Q345 | ||||
| Low and medium-pressure boiled pipe | 10,20 | GB3087-1999 | 10-530*2-40 | Over-heat pipe for low and medium pressure boiler,boiling water pipe, locomotive smoke pipe(big and small) |
| Fluid pipe | 20, Q345 | GB/T8163-1999 | 8-630*1.0-40 | Fluid feeding |
| Structural pipe | 20, Q345 10, | GB/T8162-1999 | 6-1020*1.5-100 | For common structure |
| 20,35,45, | ||||
| 16Mn,Q345B | ||||
| Line pipe | Gr.B | API | 60-630*1.5-40 | Carrying gas, water or oil in the industries of petroleum and natural gas |
| Hydraulic prop pipe | 27SiMn | GB/T17396-1998 | 70-377*9-40 | Hydraulic support and prop |
Our Services
ASTM A333 Prime Steel a335 p91 alloy steel pipe Seamless Pipe Sizes 610mm diameter pipe with 16 mm thickness
* 1 .can cut the seamless steel pipe into the length you demand
* 2 .can make the surface to be bright by milling and grinding at the Lathe
* 3 .can grind the outer diameter and wall thickness to be the dimension you demand
* 4 .can make steel pipes deep processing
If the sizes are not available from the standard common stock sizes, and the quantity are not enough for the new production, then we need process the stock larger seamless pipes into the sizes you need. For example, size OD250x ID200 is not stock common size, then need using larger pipe to process into 250x 200, same as OD170xID100
Packaging & Shipping
ASTM A333 Prime Steel a335 p91 alloy steel pipe Seamless Pipe Sizes 610mm diameter pipe with 16 mm thickness
1. Material ASTM A333 GR1, GR3, GR4, GR6, GR7, GR8. GR9, GR10, GR11, Hot Rolled Seamless steel pipes
2. OD: 6MM-400MM
3. WT: 0.5MM-60MM
4. Length: 5 meters- 12000 meters
5. Heat treatment: Quenched and tempered ; Double Normalized and Tempered; Normalized
6. Cut to order and cut to size, any size is available
steel pipe structure picture and weight counting method as follow:
Production Line & Process & Packing about our products
About Packaging.
1. by bundles, each bundle weight under 3 tons, for small outer diameter seamless steel pipe, each bundle with 4 - 8 steel strips.
2. after making by bundle, covered with Polyethylene waterproof cloth.
3. make black paints painting on each pipe, then make bundles
The factory Picture
Transportation Picture
Company Information
Tianjin Emerson Commercial and Trade Co.,Ltd has large stocks for the carbon steel and low alloy steel plates and sheets, especially have the thick plate and heavy plates on stock, also can provide the special material and large size steel plates, boiler and pressure vessel steel plate, marine steel plate, hot rolled steel plate for new production. Tianjin Emerson Commercial and Trade Co.,Ltd also has large stock for hollow bars, thick wall seamless pipes and tubes. Tianjin Emerson Commercial and Trade Co.,Ltd can provide good service for customer, good quality products, fast delivery, and after-sale service,
Tianjin Emerson hopes to build good cooperation with everyone interested.
