UNI-T Auto Range Resistance Capacitance Frequency Digital Clamp Meter UT205

Name: UNI-T Auto Range Resistance Capacitance Frequency Digital Clamp Meter UT205
Brand: UNI-T
SKU: 123609243
Availability: InStock

US$ 33 - 49 MOQ: 1 Piece

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

UNI-T

Model Number:

UT204

Huazheng Electric Manufacturing (Baoding) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Shanghai/Shenzhen/Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name UNI-T

Model Number UT204

Power Electronic

Usage Auto Testing Machine

UNI-T Auto Range Resistance Capacitance Frequency Digital Clamp Meter UT205

We are the supplier of Chinese State Grid!

Product Description

Auto Range Resistance Capacitance Frequency Digital Clamp Meter UT205

UT200 Series
1000A Digital Clamp Meter
UT205
Products
UT205 is a stable and low -power performance, safe and reliable 33 / 4 AC Digital Clamp Meter , full- range overload protection circuit , unique design and superior performance make it a special electrical instruments .
Used in smelting, manufacturing, petroleum, electric power, chemical and other industries ideal tool maintenance / repair .
Safety Level
CAT II 600V
CAT III 300V
Authenticate
CE
EN :61010-1
EN :61326-1
EN :61010-2-032

Basic functions
Model		UT205A	UT206A
AC current (A)	400A/1000A	(1.5% +5)	(1.5% +5)
AC voltage (V)	4V/40V/400V/600V	(1.2% +5)	(1.2% +5)
DC voltage (V)	400mV/4V/40V/400V/600V	(0.8% +1)	(0.8% +1)
Resistance ()	400/4K/40K/400K/4M/40M	(1% +2)	(1% +2)
Frequency (Hz)	10Hz ~ 10MHz	(0.1% +3)	(0.1% +3)
Celsius ( C)	-40 C ~ 1000 C		(2% +8)
Special Features
Maximum display		3999	3999
Auto range
Opening size		40mm	40mm
Duty Cycle	0.1% to 99.9%
Diode test
Automatic shutdown
Continuity Buzzer
Low voltage display
Digital Hold
Relative measurement
LCD backlight
Whole symbol is displayed
Input impedance	10M
General Characteristics
Power supply	9V battery (6F22)
LCD Size	37mm X 18 mm
Colors	Red + Grey
Body Weight	350g
Dimensions	236mm X 97mm X40 mm
Standard accessories	UT205A- table pen , battery, cloth
Standard accessories	UT206A- table pen , battery, point temperature probes , cloth
Standard Package	Box, manual, warranty card
Standard Packing	20
Standard Package Size	530mm X 360mm X 385mm
Standard Gross Weight	17Kg
