Home > Products > Clamp Meter > 600A True RMS Autoranging AC/DC digital WATT Clamp On Meter
600A True RMS Autoranging AC/DC digital WATT Clamp On Meter
- 1000 Unit / Units per Month
- tianjin/True RMS Clamp Meter
- T/T Credit Card
Product Details
| Place of Origin: | Hebei, China | Brand Name: | UNI-T | Model Number: | UT216D |
| Power: | Electronic | Usage: | Auto Testing Machine |
Product Description
600A True RMS Autoranging AC/DC digital WATT Clamp On Meter
MOQ: 1 PC ! The suplier of State Grid ! Standard: CE ISO!
600A True RMS Autoranging AC/DC digital WATT Clamp On Meter introduction:
600A True RMS Autoranging AC/DC digital WATT Clamp On Meter feature:
- 1,600A AC and DC current measurement;
- 2,True RMS response for ACV and ACA;
- 3,Inrush current function for AC current measurement;
- 4,V.F.C function for measuring signal at variable frequency;
- 5,Non-contact voltage detection with LED indication;
- 6,High brightness and contrast ratio Organic LED display;
- 7,Flashlight for working at dark environment;
- 8,Other functions include Capacitance, Frequency and Temperature measurements.
600A True RMS Autoranging AC/DC digital WATT Clamp On Meter specifications:
Specifications | Range | Best Accuracy |
Model | UT216D | |
AC Current (A) | 60A/600A | ±(2.5%+5) |
DC Current (A) | 60A/600A | ±(2.5%+5) |
AC Voltage (V) | 6V/60V/600V/750V | ±(1.2%+5) |
DC Voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.8%+1) |
Resistance (Ω) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ | ±(1%+2) |
Capacitance (F) | 60nF/600nF/6μF/60μF/600μF/6mF/60mF | ±(4.0%+5) |
Frequency (Hz) | 10Hz-1MHz | ±(0.1%+4) |
Temperature (°C) | -40 °C ~ 1000°C | ±(2.5%+3) |
Temperature (°F) | -40 °F ~ 1832°F | ±(2.5%+4) |
Features | ||
Display Count | 6000 | |
Auto Range | √ | |
Jaw Capacity | 30mm | |
True RMS | √ | |
Diode | Around 3.0V | √ |
V.F.C. | √ | |
NCV | √ | |
Data Hold | √ | |
Zero Mode | √ | |
Relative Mode | √ | |
MAX/MIN | √ | |
Inrush Current | √ | |
LCD Backlight | √ | |
OLED Display | √ | |
Analogue Bar Graph | 21 | |
Flishlight | √ | |
Auto Power Off | Around 15 Minutes | √ |
Continuity Buzzer | √ | |
Low Battery Indication | ≤3.6V | √ |
Input Protection | √ | |
Input Impedance for DCV | ≥10MΩ | √ |
From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.
