Essential Oil Distiller
Application:
This essential oil distiller can distill the essential oil from flowers, leaves,roots, powder and so on, it also can extract component from herbs like senna, stevia, licorice and so on.
Structure Drawing:
Structure: oil distiller, oil-water separator,receiver, oil cooling system, plate distillation system Vacuum system, frame,Pipes,valves, digital temperature sensor.
Principle:
First you put the raw material into the extractor,
Then heat the steam boiler, the steam boiler produce the steam which will directly distill the raw material in the extractor, then the essential oil will come out from the herbs, flowers, leaves and so on, the essential oil and the steam will be cooled by condenser which flow back to water-oil seperator, the oil will flow to oil storage tank, the water will flow to water storage tank, and the water flow to steam boiler again, so it is circulation.
Character:
1. By steam-distillation to reach the extraction of essential oils. Easy operation. One people can operate this machine easily.
2. It is heated by steam
3. Save energy: the steam from steam generator which directly distill the raw material, and the steam will be cooled by condenser, and seperate the water from oil from seperator, the water can flow back to steam boiler again, so the purity water can be circulation.
4. All the machine have not dead corner, so it is good to clean and it is according GMP standard.
5. All surface of the machine is mirror polished, so it is looks very beautiful.
Parameter:
Model Items |
TQ-100 |
TQ-300 |
TQ-500 |
TQ-1000 |
TQ-3000 |
TQ-6000 |
Extraction volume(L) |
100 |
300 |
500 |
1000 |
3000 |
5000 |
Working pressure in jacket |
<0.2Mpa |
|||||
Working pressure in pot(Mpa) |
<0.1Mpa |
|||||
Extract Temperature(℃) |
50-100 |
|||||
Heat Medium |
Steam |
|||||
Material |
Stainless steel |
|||||
1.How much liter of this machine do you need?we have 50L 100L 200L 300L 500L 1000L .......10000L and so on.
2 .What is your raw material? Is it leaves, stem, Flower or root?
3 .How much percent of the essential oil from the raw material?
4 .When do you need this machine?
User demands analysis
Engineering design
Product manufacturing
Automatic control integration
Certification service
Engineers are available to go abroad to help installation
All the products before delivery should be tested by assemble&debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.
All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading&uploading, the upward mark will be posted on the wooden case.
Our company is professional to manufacture and export pharmaceutical machine, food machine. Machines include:
Pharmaceutical machine:
Tablet press machine, blister packing machine, capsule filling machine, capsule / tablet counting production line, soft capsule making machine, mixing machine.
Liquid filling machine:
Vial filling machine, ampoule filing machine, wrapping machine, tube filling and sealing machine.
Food machine:
Jam, butter, chocolate packing machine, food tablet press machine and so on.
Export:
Machines have exported to South America, Europe, South-east Asia, and so on.
Welcome to contact with us.
