Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Liquid Packing & Packaging Machine For Soy Sauce Vinegar Wine Soymilk Milk

Liquid Packing & Packaging Machine For Soy Sauce Vinegar Wine Soymilk Milk

Name: Liquid Packing & Packaging Machine For Soy Sauce Vinegar Wine Soymilk Milk
Brand: Sunny
SKU: 123565117

Liquid Packing & Packaging Machine For Soy Sauce Vinegar Wine Soymilk Milk thumbnail-1

Liquid Packing & Packaging Machine For Soy Sauce Vinegar Wine Soymilk Milk photo-1

US$ 39,000 - 44,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Chemical, Commodity, Food, Medical

Packaging Type:

Bags, Pouch, Stand-up Pouch

Contact Supplier Request Quote Chat Now

Zhejiang Sunny Machinery Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Or Ningbo Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Chemical, Commodity, Food, Medical

Packaging Type Bags, Pouch, Stand-up Pouch

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 12KW

Place of Origin Zhejiang, China

Brand Name Sunny

Model Number DXDO-Y900E

Weight 1500KG

Dimension(L*W*H) 1650x1500x2200mm

Certification CE ISO GMP

After-sales Service Provided Engineers available to service machinery overseas

DXDO-Y900E Automatic Liquid Filling Machine

Usage

Machine is suitable for packing liquid material in the medicine, food, and daily chemical industries, and automatic packing into sachets with measuring requirement. Such as pesticides, strong acidic liquid materials, medicine (water), chemical agent (water) and so on.

Characteristic

1. Advanced performance, high power, low noise, compact structure, operate steadily , easy to maintain, and has a long life span.

2.Adopt five shaft servo motor in step driver, man-machine interface touch adjustment, controlled by PLC, it is precise in automatic in step positioning.

3. A high degree of automation. Machine can finish packing at one time from longitudinal sealing, longitudinal cutting, transverse sealing, filling, embossing, notch cutting, cutting Dotted line, transverse cutting to outputting finished sachets.

4. High precision whole rolling type heat sealing rollers are adopted as sealing mould. 4-sides sealing, multi-line sachets form. With high packing speed, smooth bag shape, delicate and beautiful, packaging with high efficiency

5. Fast and convenient to adjust. It can step-less adjusting pouch length without changing the mould. And can adjust the functions as longitudinal sealing, transverse sealing, filling, embossing, Dotted line cutting and transverse cutting through man-machine interface.

6. Accurate in measurement. According to causticity stronger liquid material, specially match with peristaltic liquid pump for filling, high precise measuring control, every line bag match with a pump, each line’s dosage can be adjusted easily and accurately.

7. Photoelectric tracking system is adopted to ensure correct printing and with automatic counting function.

8. Adaptability of the package film. The sealing temperature of machine is with automatic control, and with high control accuracy (± 1C °). Suitable for most complex film packing film in home and abroad, such as PET/AL/PE,PET/PE,NY/AL/PE,NY/PE and so on.

9. Extra functions set up. For example, sachet cutting can choose dotted line knife, flat cutting knife or abnormal shape knife. And can choose different kinds of alarm requirement.

Main technological parameter:

Item / Model	DXDO-Y900EU
Pouch length	50~300mm (adjustable)
Pouch width	32~105mm ( if change width, should change bag mould)
Packing speed	20~40times/nim(depend on the pouch size and material)
Filling capacity	5~100ml
Applicable film	PET/AL/PE PET/PE NY/AL/PE NY/PE
Max film width	900mm
Max film diameter	Φ300mm (do as customer’s request)
Film core diameter	Φ75mm (do as customer’s request)
Electric source	380V50Hz (do as customer’s request)
Total power	12 kw
G.M	1500kg
Package size	1650x1500x2200mm (L×W×H)

Accessory:

Product name	Brand
PLC/ Programmable controller PLC	JAPAN MITSHUBISH
TOUCHING SCREEN	TAIWAN WEINVIEW
AC CONTACTOR	GERMANY SIMEN
INTERMEDIATE RELAY	JAPAN OMRON
SOLID RELAY	JAPAN OMRON
TEMP.CONTROLLER	JAPAN OMRON
COLOUR MARK SENSOR	GERMANY SICK
PROXIMITY SWITCH	GERMANY SICK
SCRAM BUTTON	FRENCH SCHNEIDER
MOTOR	CHINA
SPEED REDUCER	ZHEJIANG HANGZHOU
SERVO MOTOR	JAPAN MITSHUBISH
SERMP DRIVE	JAPAN MITSHUBISH
AIR SWITCH	CHINT GROUP
SWITCH POWER	TAIWAN MEAN WELL
FEEDING ELECTRO-MAGNETIC VALVE	Japan SMC
SLITTER	HIGH SPEED TOOL STEEL
HEATING PIPE	STAINLESS
COVER	304 STAINLESS

Our Services

User demands analysis

Engineering design

Product manufacturing

Automatic control integration

Certification service

Engineers are available to go abroad to help installation

Packaging & Shipping

All the products before delivery should be tested by assemble&debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.

All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading&uploading, the upward mark will be posted on the wooden case.
