SCF series electric frequency changing motor control cabinet made in China
Specification:
Our SCF device adopts frequency conversion technology and microelectronic technique, controlling electric control device of AC motor by changing motor working power frequency. The frequency converter is consisted of rectification, filtering, rectification, braking unit, driving unit, detecting unit, micro-process unit .
The IGBT’s on-off can adjust output power voltage and frequency, achieving the function of energy saving and speed control according to the actual motor condition.
Application:
Successfully widely used by national engineering designing institute, mining company, cement mill, stell mill, sugar factory, wood industry, chemical industry, city planning, and other place with big power motor and high electric consume place.
Operating Environment:
a. The ambient temperature upper limit and lower limit are respectively +40°C and -10°C;
b. Altitude is not more than 1000m(if it exceeds 1000m, we will choose plateau style);
c. Relative humidity: daily average value should not be more than 85%, while monthly average value should not be more than 90% ;
d. Seismic intensity should be not more than 5°;
e. Places without fire, explosion risk, serious pollution, chemical corrosion and violent vibration.
Executive standard:
GB/T3859.1-1993
GB/T3859.2-1993
GB/T13422-1992
GB/T12668-1990
Technical parameter:
10kV high voltage motor frequency converter speed controller
Model |
Adaptive power(kW) |
External dimension(mm) |
Remark |
||
W |
D |
H |
|||
SCFH- 500/10 |
≤ 500 |
3700 |
1200 |
2300 |
separate(three parts) |
SCFH- 1000/10 |
≤ 1000 |
4200 |
1200 |
2300 |
separate(three parts) |
SCFH- 1500/10 |
≤ 1500 |
4500 |
1200 |
2300 |
separate(three parts) |
SCFH- 2000/10 |
≤ 2000 |
4800 |
1300 |
2300 |
separate(three parts) |
SCFH- 3000/10 |
≤ 3000 |
5400 |
1400 |
2300 |
separate(three parts) |
SCFH- 4000/10 |
≤ 4000 |
5400 |
1400 |
2400 |
separate(three parts) |
SCFH- 5000/10 |
≤ 5000 |
5700 |
1500 |
2500 |
separate(three parts) |
SCFH- 6000/10 |
≤ 6000 |
10200 |
1500 |
2500 |
separate(three parts) |
SCFH- 7000/10 |
≤ 7000 |
10200 |
1500 |
2500 |
separate(three parts) |
SCFH- 8000/10 |
≤ 8000 |
10200 |
1500 |
2500 |
separate(three parts) |
SCFH- 9000/10 |
≤ 9000 |
10200 |
1500 |
2500 |
separate(three parts) |
SCFH-10000/10 |
≤10000 |
10200 |
1500 |
2500 |
separate(three parts) |
SCFH- /10 |
>10000 |
Special design |
|
||
6kV high voltage motor frequency converter speed controller
Model |
Adaptive power(kW) |
External dimension(mm) |
Remark |
||
W |
D |
H |
|||
SCFH- 500/6 |
≤ 500 |
3600 |
1200 |
2300 |
separate(three parts) |
SCFH- 1000/6 |
≤ 1000 |
3600 |
1200 |
2300 |
separate(three parts) |
SCFH- 1500/6 |
≤ 1500 |
3800 |
1300 |
2300 |
separate(three parts) |
SCFH- 2000/6 |
≤ 2000 |
4100 |
1300 |
2300 |
separate(three parts) |
SCFH- 3000/6 |
≤ 3000 |
4500 |
1400 |
2300 |
separate(three parts) |
SCFH- 4000/6 |
≤ 4000 |
4700 |
1400 |
2400 |
separate(three parts) |
SCFH- 5000/6 |
≤ 5000 |
5700 |
1400 |
2400 |
separate(three parts) |
0.4kV low voltage motor frequency converter speed controller
Model |
Adaptive power(kW) |
External dimension(mm) |
Remark |
||
W |
D |
H |
|||
SCFL- /0.4 |
22 ~ 30 |
600 |
600 |
1800 |
integrated(one part) |
SCFL- /0.4 |
37 ~ 55 |
600 |
600 |
1800 |
integrated(one part) |
SCFL- /0.4 |
75 ~ 110 |
800 |
600 |
2000 |
integrated(one part) |
SCFL- /0.4 |
132 ~ 185 |
800 |
800 |
2000 |
integrated(one part) |
SCFL- /0.4 |
200 ~ 315 |
1000 |
800 |
2200 |
integrated(one part) |
SCFL- /0.4 |
350 ~ 500 |
1200 |
800 |
2200 |
separate(two parts) |
Ordering notice:
When you order this device, please provide information about motor model, rated power, rated voltage, rated current, load type and so on.
Certificates:
Welcome to visit our factory!
Any query and question please be free to contact with us.
It’s our great pleasure to help you.
