Help CenterFlexible Stainless Tube for Optical Protection
Related Products
-
Galvanized Steel Flexible ConduitNegotiableMOQ: 500 Meters -
Faucet Flexible Hose (FA-B1-02)US$ 1.9 - 4.5MOQ: 300 Pieces
-
Mini Armoured 4 Core Fiber Optic CableNegotiableMOQ: 500 Meters
-
Flexible Metal TubeNegotiableMOQ: 500 Meters
-
Stainless Steel Flexible Metal Hose PipeNegotiableMOQ: 500 Meters
| flexible stainless tube for optical protection |
Monocoil Tube (Fiber Optic Protection Tube / Spiral Protection Tube) is in micro diameter and light weight. Excellent flexibility offers the convenience and ease of deployment at corners and prevents the line from damage. After covering with SUS braiding, the tube is capable to resist press and improper twist. Reinforced tensile strength can be reached by using Kevlar. The material of outer coating can be made according to environment conditions and can be recognized by 12 colors.
Feature
Tube Material: Stainless Steel
Braiding Material: Stainless Steel
ID: ø1.0 ~ ø8.0m
OD: ø1.5 ~ ø8.8mm
OD with Braiding: ø1.9 ~ ø9.5mm
OD with Braiding & Coating: ø2.5 ~ ø11.0mm
Coating Material: PVC / HDPE / LDPE / LSZH
Coating Color: Black / Grey
Temperature Range: -20 °C ~ 70 °C
| Code | ID (ø mm) |
OD (ø mm) |
OD w/Braiding (ø mm) |
OD w/Braiding & Coating(ø mm) |
Min. Bending Radius(mm) | Packing Length(m) |
| TMC-001 | 1.0 | 1.5 | 1.9 | 2.5 | Dynamic = 20 x D Static = 10 x D (D= Optic Dia.) |
1000 |
| TMC-002 | 1.1 | 1.6 | 2.0 | 3.0 | 1000 | |
| TMC-003 | 1.5 | 2.1 | 2.6 | 3.3 | 1000 | |
| TMC-004 | 2.2 | 2.8 | 3.4 | 5.0 | 1000 | |
| TMC-005 | 3.0 | 3.8 | 4.5 | 6.0 | 1000 | |
| TMC-006 | 4.0 | 4.8 | 5.5 | 7.0 | 1000 | |
| TMC-007 | 4.6 | 5.5 | 6.2 | 7.5 | 1000 | |
| TMC-008 | 5.0 | 5.8 | 6.5 | 8.0 | 1000 | |
| TMC-009 | 6.0 | 6.8 | 7.5 | 9.0 | 1000 | |
| TMC-010 | 7.0 | 7.8 | 8.5 | 10.0 | 1000 | |
| TMC-011 | 8.0 | 8.8 | 9.5 | 11.0 | 1000 |
Application
Mainly for fiber optic protection, such as sensing system and communications equipment, besides, endoscopy or laparoscopy as well.
