GGD Series Low voltage Fixed Panel Board, Switch Panel, Switch Board
GGD series A.C. low voltage switchgear is suitable to power plants, substations, and industrial enterprises as, energy conversion, distribution and control of power, illumination and distribution equipments for the distribution system which frequency is 50HZ, rated voltage is 380V and rated current is up to 3150A.
Operating environment:
1)Ambient temperature:-10°C-+40°C;
2)Altitude: high voltage ≤1000Meter, low voltage ≤2000Meter (technical department will design specially if exceeds);
3)Relative humidity:≤85%
4)Seismic intensity:≤ magnitude 8;
5)Apply to the places have no fire,no explosion danger, no serious pollution,no chemical corrosion and no violent vibrationExecutive standard:
GB7251 Low voltage complete set switchgear and control device
Technical parameter:
0.4KV low voltage switchgear technical parameter:
|
|
Parameter |
||
Rated voltage |
V |
400 |
690 |
|
Rated insulation voltage |
V |
690 |
1140 |
|
Rated impact withstand voltage |
V |
6000 |
10000 |
|
Rated working short circuit breaking ability |
kA |
18~100 |
10~75 |
|
Rated utmost short circuit breaking ability |
kA |
25~120 |
20~85 |
|
Rated frequency |
Hz |
50/60 |
||
Rated current |
A |
400,500,630,800,1000,1250,1600,2000,2500,3150,4000,5000,6300 |
||
Rated control power |
V |
AC 110/220/380,DC 110/220 |
||
|
Dimension (Unit:mm) |
MNS/GCS/GGD |
width |
400,600,800,1000,1200 |
|
depth |
600,800,1000 |
|||
height |
2200 |
|||
Ordering notice:
Please provide system capacity, system voltage, electric scheme, function requirement, configuration requirement when you decide to order.
KYN61-40.5 metal-cased closed switchgear (35KV)
KYN28A-24 metal-cased closed switchgear (20KV)
KYN28A-12 metal-cased closed switchgear (10KV)
XGN2-12 box-type fixed indoor AC electrical switchgear (10KV)
XGN15-12 box-type fixed indoor AC electrical ring net cubicle (10KV)
MNS low voltage drawer switchgear
GCS low voltage drawer switchgear
GGD low voltage fixed switchgear
1 Reply your enquiry in 24 working hours.
2 Experienced staffs answer all your questions in professional and fluent English.
3 Customized design is available. OEM&ODM are welcome.
4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs.
5 Special discount and protection of sales area provided to your distributor.
6 Do the best electric cabinet in China.
Location: Xiangyang, China(Mainland)
Year Established: 2008
Registration No: 420600000118942
Company Certifications: ISO 9001; ISO14001; OHSAS 18001; CCC; TUV
Main products: Power quality cabinets; Motor control cabinets; Switchgear complete sets
2,Our company view
Hubei Zhongsheng Electric Co., Ltd
Add: No.38 Building of Jiahai Industrial Park , High-tech Zone, Xiangyang City ,Hubei Province.
Email:
skype chinastrong001
Tel: 0086 710-3119828 Fax: 0086 710-3253158 QQ: 2693994091
Send your enquiry details in the below form ,click "Send" now!
