Home > Construction & Decoration > Heat Insulation Material > Glass Wool > Electrical Shielding Tape
Electrical Shielding Tape
US$ 2,000 - 3,900
MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Tianhong
Model Number:
PET
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mylar Tape for CableUS$ 3,000 - 4,500MOQ: 1 Ton -
Polyester Insulation TapeUS$ 3,000 - 4,500MOQ: 1 Ton
-
Aluminum Polyester Foil for Telecommunication EquipmentUS$ 3,000 - 5,000MOQ: 0 Ton
-
Auminium Foil Lamination for Telecommunication EquipmentUS$ 3,000 - 4,500MOQ: 1 Ton
-
Heat Sealable Aluminum Foil for Optical Cable ShieldingUS$ 3,000 - 4,500MOQ: 1 Ton
Place of Origin
Zhejiang, China
Brand Name
Tianhong
Model Number
PET
Type
Insulation Tape
Material
PET
Application
High Temperature
Rated Voltage
Customer requirements
Tensile Strength
≥80 Mpa
Specifications
1.For insulating, jelly filled telephone cable, videotape2.Printing,packaging,covering
3.Metalizing,lamination
4.Capacitor
Usage:
1.For insulating, jelly filled telephone cable, videotape
2.Printing,packaging,covering
3.Metalizing,lamination
4.Capacitor
Specifications:
Thickness |
0.012mm-0.25mm |
Width |
5mm-2000mm |
Inner diameter(ID) |
38mm or 53.5mm or 76mm or 150mm 1.5in or 2.1in or 3.0in or 5.9in |
Outer diameter(OD) |
250-550mm |
Color |
Clear,Milk |
structure |
Thickness |
weight(gr/m2) |
Yield(m2/kg) |
PET film |
12mic |
16.5 |
60 |
PET film |
15mic |
20.6 |
48 |
PET film |
20mic |
27.7 |
36 |
PET film |
25mic |
34.7 |
28 |
PET film |
30mic |
41.2 |
24 |
PET film |
35mic |
48.2 |
20 |
PET film |
40mic |
55.3 |
18 |
PET film |
50mic |
68.8 |
14 |
PET film |
60mic |
82.3 |
12 |
PET film |
70mic |
94.5 |
10 |
Contact:
Mobile:+86-15168349992
TEL:+86-571-6106 1089
FAX:+86-571-6381 0799
Test report
| No. | Name | Width(mm) | Thickness (mm) |
Tension (N) |
Tensile strength (MPa) |
Elongation at break (%) |
| 1 | PET | 20.000 | 0.036 | 140.70 | 195.418 | 153.690 |
| 2 | PET | 35.000 | 0.036 | 214.42 | 170.177 | 130.323 |
| 3 | PET | 50.000 | 0.036 | 274.78 | 152.657 | 89.772 |
| Max | 0.00 | 50.00 | 0.04 | 274.78 | 195.42 | 153.69 |
| Min | 0.00 | 20.00 | 0.04 | 140.70 | 152.66 | 89.77 |
| Average | 0.00 | 35.00 | 0.04 | 209.97 | 172.75 | 124.59 |
