Help CenterMylar Tape for Cable
US$ 3,000 - 4,500
MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Tianhong
Model Number:
Customer requirements
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polyester Insulation TapeUS$ 3,000 - 4,500MOQ: 1 Ton -
Aluminum Polyester Foil for Telecommunication EquipmentUS$ 3,000 - 5,000MOQ: 0 Ton
-
Auminium Foil Lamination for Telecommunication EquipmentUS$ 3,000 - 4,500MOQ: 1 Ton
-
Heat Sealable Aluminum Foil for Optical Cable ShieldingUS$ 3,000 - 4,500MOQ: 1 Ton
-
Clear Color Mylar Film for Insulation MaterialsUS$ 3,000 - 4,500MOQ: 1 Ton
Place of Origin
Zhejiang, China
Brand Name
Tianhong
Model Number
Customer requirements
Type
Insulation Tape
Material
PET
Application
High Temperature
Rated Voltage
5 KV
Tensile Strength
≥50Mpa
Specifications
1.Mylar strip provides cladding and insulating for internal structure of the cable2.Printing,packaging,covering
Usage:
1.For insulating, jelly filled telephone cable, videotape
2.Printing,packaging,covering
3.Metalizing,lamination
4.Capacitor
Specifications:
structure |
Thickness |
weight(gr/m2) |
Yield(m2/kg) |
PET film |
12mic |
16.5 |
60 |
PET film |
15mic |
20.6 |
48 |
PET film |
20mic |
27.7 |
36 |
PET film |
25mic |
34.7 |
28 |
PET film |
30mic |
41.2 |
24 |
PET film |
35mic |
48.2 |
20 |
PET film |
40mic |
55.3 |
18 |
PET film |
50mic |
68.8 |
14 |
PET film |
60mic |
82.3 |
12 |
PET film |
70mic |
94.5 |
10 |
Thickness |
0.012mm-0.25mm |
Width |
5mm-2000mm |
Inner diameter(ID) |
38mm or 53.5mm or 76mm or 150mm 1.5in or 2.1in or 3.0in or 5.9in |
Outer diameter(OD) |
250-550mm |
Color |
Clear,Milk |
Test report:
| No. | Name | Width (mm) |
Thickness (mm) |
Tension (N) |
Tensile atrength (MPa) |
Elongation at break (%) |
| 1 | PET | 20 | 0.036 | 391.97 | 139.99 | 138.616 |
| No. | Name | Width(mm) | Thickness (mm) |
Tension (N) |
Tensile strength (MPa) |
Elongation at break (%) |
| 2 | PET | 40.000 | 0.025 | 167.60 | 167.596 | 84.233 |
