Specifications
Commerical swimming dehumidifier1.Capacity:5.9L-200+L
2.Extending heat water
3.For corrosive enjoinments
4.Titanium water
Commerical swimming dehumidifier
Product Description
Swimming pool room indoor dehumidifier.
This kind of home application dehumidifier is used in indoor pools,which is also using the latent heat of evaporation and the performance of the system itself to heat the pool water and the room air,and to control the three parameters which define comfort in a swimming pool: water, air and relative humidity
Featured Highlights
1.Expansion valve with pressure balancing unit
2.Full regulation of all elements of the unit
3.Evaporator,condenser,hot water unit,made of copper tube with coated aluminum fins(special for corrosive enjoinments)
Calculations based on an air temperature of 27°C at 60% RH-15 °C at 60% RH12m3/h flow rate.Water at 24°C
| |
Models | FN type Dehumidifying heat pump machines | ||||||||
| Parameters | FN7 | FN9 | FN11 | FN13 | FN18 | FN23 | FN26 | FN32 | ||
| humidity capacity(kg/h) | 7 | 9 | 11 | 13 | 18 | 23 | 26 | 32 | ||
| recycle kw (water condenser) | 9 | 10.8 | 13.8 | 16.2 | 19.5 | 25 | 28.5 | 33 | ||
| recycle kw (air condenser) | 6 | 7.2 | 9.2 | 10.8 | 12.5 | 17 | 19.5 | 22 | ||
| condenser | ||||||||||
| water condenser quantity | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | ||
| flow(m3/hr) | 4 | 5 | 5 | 7 | 7 | 8 | 10 | 11 | ||
| pressure(kpa) | 23 | 25 | 25 | 27 | 27 | 29 | 29 | 36 | ||
| Air condenser quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| loop quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| inlet-outlet size(mm) | 50/40 | 50/41 | 50/42 | 50/43 | 50/44 | 50/45 | 63/50 | 63/51 | ||
| Compressor | ||||||||||
| quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| type | vortex | vortex | vortex | vortex | vortex | vortex | vortex | vortex | ||
| power supply(V/PH/HZ) | 380/3/50 | 380/3/51 | 380/3/52 | 380/3/53 | 380/3/54 | 380/3/55 | 380/3/56 | 380/3/57 | ||
| normal power(kw) | 2.65 | 2.82 | 3.24 | 4.61 | 5.41 | 6.84 | 7.76 | 8.98 | ||
| normal current(A) | 4.9 | 5 | 5.7 | 8 | 9 | 12.6 | 14.4 | 16.7 | ||
| Ventilator | ||||||||||
| type | centrifugal | centrifugal | centrifugal | centrifugal | centrifugal | centrifugal | centrifugal | centrifugal | ||
| quantity | 1+1 | 1+1 | 1+1 | 1+1 | 1+1 | 1+1 | 1+1 | 1+1 | ||
| blowing rate(m3/h) | 4000 | 5000 | 5000 | 6000 | 8000 | 10000 | 10000 | 12000 | ||
| blowing pressure(pa) | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | ||
| motor power(kw) | 1.1/0.55 | 1.5/0.8 | 1.5/0.8 | 1.8/1.1 | 2.2/0.75 | 3/1.1 | 3/1.1 | 3/1.5 | ||
| normal current(A) | 2.8/1.6 | 3.4/2.5 | 3.4/2.5 | 3.8/2.9 | 4.89/1.92 | 6.39/2.7 | 6.39/2.7 | 6.39/3.51 | ||
| power supply(V/PH/HZ) | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | ||
| Evaporator | ||||||||||
| type | copper tube aluminum fin | |||||||||
| quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| loop quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| frontal area(m2) | 0.3 | 0.3 | 0.4 | 0.4 | 0.4 | 0.54 | 0.54 | 1 | ||
| Others | ||||||||||
| total recycle(kw) | 15 | 18 | 23 | 27 | 32 | 42 | 48 | 55 | ||
| freezing medium model | R407C | R407C | R407C | R407C | R407C | R407C | R407C | R407C | ||
| machines total weight(kg) | 234 | 240 | 350 | 450 | 600 | 720 | 1100 | 1270 | ||
| main unit size(l*w*h cm) | 67*130*165 | 67*130*165 | 67*130*165 | 67*130*165 | 200*180*122 | 200*180*122 | 200*180*122 | 200*180*122 | ||
| all sets size(l*w*h cm) | 188*130*165 | 188*130*165 | 188*130*165 | 188*130*165 | 350*180*122 | 350*180*122 | 350*180*122 | 350*180*122 | ||
What do we do?
We Provide high-quality service for:
1,Swimming pool equipment wholesalers.
2,Retailers and online shops.we have shops in Chengdu,Shanghai,Beijing and Guangzhou,We supply the high quality and low price,and best service.
3,OEM-The custom-made pumps are available.Upon customer’s idea,drawings,photos etc.more detail.The length of time depend on the procedures.
Remarks:
1.PAYMENT: 60% T/T prepaid,Western Union.
2.Terms of payment:All payment are before shipment.
3.Loading port:Huangpu Guangzhou
4.MOQ:1 pcs.
Company information:
Addr: Fl.2, No.166, Gangdong Rd., Dashi street, Panyu District, Guangzhou.China.
Tel: +86 20 34796181 Fax: +86 20 34796171.
Exhibitions:
1.Company shows:
2.Company certificate:
3.Warehouse:
