Commerical Indoor Swimming Pool Dehumidifier

Commerical Indoor Swimming Pool Dehumidifier thumbnail-1
Commerical Indoor Swimming Pool Dehumidifier photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hydroswim
Model Number:
FN6-FN163
Contact Supplier Request Quote Chat Now
Guangzhou Chuangwen Pool & Sports Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Hydroswim
Model Number FN6-FN163

Specifications

Commerical swimming dehumidifier
1.Capacity:5.9L-200+L
2.Extending heat water
3.For corrosive enjoinments
4.Titanium wat



Product Description

           Commerical indoor swimming pool dehumidifier



Product Description:



This kind of home application dehumidifier is used in indoor pools,which is also using the latent heat of evaporation and the performance of the system itself to heat the pool water and the room air,and to control the three parameters which define comfort in a swimming pool: water, air and relative humidity



Featured Highlights :



1.Expansion valve with pressure balancing unit
2.Full regulation of all elements of the unit
3.Evaporator,condenser,hot water unit,made of copper tube with coated aluminum fins(special for corrosive enjoinments)







Calculations based on an air temperature of 27°C at 60% RH-15 °C at 60% RH12m3/h flow rate.Water at 24°C



Commerical indoor swimming pool dehumidifier



Technical Details:










 Models FN type Dehumidifying heat pump machines
Parameters   FN7 FN9 FN11 FN13 FN18 FN23 FN26 FN32
humidity capacity(kg/h) 7 9 11 13 18 23 26 32
recycle kw (water condenser) 9 10.8 13.8 16.2 19.5 25 28.5 33
recycle kw (air condenser) 6 7.2 9.2 10.8 12.5 17 19.5 22
condenser
water condenser quantity 1 1 1 1 1 1 2 2
flow(m3/hr) 4 5 5 7 7 8 10 11
pressure(kpa) 23 25 25 27 27 29 29 36
Air condenser quantity 1 1 1 1 1 1 1 1
loop quantity 1 1 1 1 1 1 1 1
inlet-outlet size(mm) 50/40 50/41 50/42 50/43 50/44 50/45 63/50 63/51
Compressor
quantity 1 1 1 1 1 1 1 1
type vortex vortex vortex vortex vortex vortex vortex vortex
power supply(V/PH/HZ) 380/3/50 380/3/51 380/3/52 380/3/53 380/3/54 380/3/55 380/3/56 380/3/57
normal power(kw) 2.65 2.82 3.24 4.61 5.41 6.84 7.76 8.98
normal current(A) 4.9 5 5.7 8 9 12.6 14.4 16.7
Ventilator
type centrifugal centrifugal centrifugal centrifugal centrifugal centrifugal centrifugal centrifugal
quantity 1+1 1+1 1+1 1+1 1+1 1+1 1+1 1+1
blowing rate(m3/h) 4000 5000 5000 6000 8000 10000 10000 12000
blowing pressure(pa) 350 350 350 350 350 350 350 350
motor power(kw) 1.1/0.55 1.5/0.8 1.5/0.8 1.8/1.1 2.2/0.75 3/1.1 3/1.1 3/1.5
normal current(A) 2.8/1.6 3.4/2.5 3.4/2.5 3.8/2.9 4.89/1.92 6.39/2.7 6.39/2.7 6.39/3.51
power supply(V/PH/HZ) 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50
Evaporator
type copper tube aluminum fin
quantity 1 1 1 1 1 1 1 1
loop quantity 1 1 1 1 1 1 1 1
frontal area(m2) 0.3 0.3 0.4 0.4 0.4 0.54 0.54 1
Others
total recycle(kw) 15 18 23 27 32 42 48 55
freezing medium model R407C R407C R407C R407C R407C R407C R407C R407C
machines total weight(kg) 234 240 350 450 600 720 1100 1270
main unit size(l*w*h cm) 67*130*165 67*130*165 67*130*165 67*130*165 200*180*122 200*180*122 200*180*122 200*180*122
all sets size(l*w*h cm) 188*130*165 188*130*165 188*130*165 188*130*165 350*180*122 350*180*122 350*180*122 35



 Notices:



1.Payment: 70% T/T prepaid,Western Union.

  2.Terms of payment:All payment are before shipment .

 3.Price will be adjusted if USD:RMB rate varies by +/- 2%. Freight not included .

 4.Offer validity: one month.
