1080P 10/100Mbps + 2Gigabit TP/SFP Fast Ethernet IEEE802.3af 230 Watts 1U Size 16 Port POE Switch
Key Features
* 16 Port 10/100Mbps+2 Gigabit TP/SFP
* Up to 15.4W of Power on
* Complies to IEEE 802.3af PoE standard and is backward
* Compatible with All IEEE 802.3af or Legacy
* Safe: Low Power Devices Receive Only the Power They Need
* Safe and Reliable Power to WLAN Access Points
* Automatic Detection and Protection of Non–standard Ethernet Terminals
* Supports 10/100 Base-T applications
* Compact Design Fits Easily in WLAN Access
* Plug-and-Play no configuration required
* Internal power supply
* Save up to 83% power with Green Technology
Technical Specification
Pass Through Data Rates |
16 Port 10/100Mbps+2 Gigabit TP/SFP |
PoE Standard |
IEEE 802.3af |
LED |
Power (Green) |
PoE In-Use (Orange) | |
10/100 LNK / ACT(Green) | |
Dimension (WxDxH)/Weight |
440 x 208 x 44 mm, 4kg |
Power Requirement |
100~240V AC, 50-60 Hz |
Power Consumption |
250 Watts maximum |
PoE Power Output |
Per Port 54V DC, 350ma. Max. 15.4 Watts |
PoE Power Supply Type |
1/2(+), 3/6(-), Mode-A, End-Span |
PoE Power Budget |
System: 250W; PoE: Max. 230W |
Storage |
Temperature: -10 ~ 70 Degree C |
Operating |
Relative Humidity: 20 ~ 95% (non-condensing) |
Temperature: 0 ~ 50 Degree C | |
Relative Humidity: 20 ~ 95% |
Packing list:
The POE Switch *1
User’s Manual *1
19” Rack mount Accessory Kit *1
Power Cord *1(US/EU/UK/AU)
Rubber Feet *4
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. Whole life service for continue cooperating customers!
Price Term:
FOB Shenzhen
Delivery Term:
By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
